HOFF CSD12126

Enclosure 12.00x12.00x6.00

Page Loading...
NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
Enclosure 12.00x12.00x6.00

Mouse over image to zoom, click to enlarge

Description:
Enclosure 12.00x12.00x6.00

UPC:  78351077290

Part Number: CSD12126

UNSPSC: 39121324

Status:  UNKNOWN

Retail Price:  $401.00 / EA
Your Price:  $374.27 / EA


Quantity  EA

Specifications

Manufacturer Name NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
MfgPartNo CSD12126
Additional Information RoHS Compliant; Application Machine Control; Applicable Standard IEC 60529, VDE
Application Controls and Drives
Approval UL 508A, CUL, CSA C22.2
Back Panel CP1212, CP1212G
Base Price 0.0000
Body Thickness Imperial 16 ga
Body Thickness Metric 1.52 mm
Brand Name nVent HOFFMAN;CONCEPT
Catalog Number CSD12126
Color Gray;ANSI 61 Gray
Color Code ANSI 61
Commerce Sector Construction Materials
Commodity Code 36160
Commodity Description Nema Types 4 & 12 Metallic Enclosures, Boxes, Cabinets
Concept Panel CP1212
Conductive Concept Panel CP1212G
CountryOfOrigin US
Cover Type Hinged with Removable Pin, Foam Gasketed, Quarter Turn Latch
DDCATEGORY 1962
Depth 6;6 Inch
Directory CIS
Door Thickness Imperial 16 ga
Door Thickness Metric 1.52 mm
Enclosure NEMA 4/12/13, IP66
Families 1962
Family Description Nema Types 4 & 12 Metallic Enclosures, Boxes, Cabinets
Finish Powder Coat;Textured Polyester Powder Coated
Height 12 in;12 Inch
IP Rating IP66
Image Location * Image
Industry ELX
InvoiceDescription Enclosure 12.00x12.00x6.00;ENCLOSURE
Item Number 77290
Latch Quantity 1
Latch Style Quarter-turn
Long Description WALL MOUNT ENCLOSURE, 1-DOOR TYPE; MILD STEEL MATERIAL; TEXTURED POLYESTER POWDER COATED FINISH; ANSI 61 GRAY COLOR; 12 INCH; 12 INCH; 6 INCH; UL 508A, CUL, CSA C22.2 APPROVAL; WALL MOUNTING; NEMA 4/12/13, IP66 ENCLOSURE
MSDS Form Number *
Material Mild Steel
Material Specification 16 Gauge (Door), 18 Gauge (Body)
Model CW1
Modification Services Yes
Mounting Wall
Mounting Imperial 10.50 x 10.50 in
Mounting Metric 267 x 267 mm
NEMA Rating 12 Indoor, dust-resistant
Noun *
Panel Size Imperial 10.20 x 10.20 in
Panel Size Metric 259 x 259 mm
Product Description Enclosure 12.00x12.00x6.00
Product Family Concept
Product Keywords WEBREADY
Product Name Electrical general purpose enclosure
ProductLine HOFF
Protection Rating NEMA Type 12
Size 12.00x12.00x6.00 in
Sub Brand Concept
Type Mild Steel Wall Mounted Industrial Enclosures;1-Door
Type Number Type 4
UNSPSC 39121324
UPC 78351077290
Vendor Name NVENT HOFFMAN
Vendor Number 783510
Vendor Short Name HOFF
Weight Imperial 13.2 lb
Width 12 in;12 Inch

Resources

CatalogNumber CSD12126
Full Image
MfrProductUrl

Package Information

SellPkgQty 1
