HOFF CSD242410

Encl Concept 1-Door MS GY 24x24x10

Page Loading...
NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
Encl Concept 1-Door MS GY 24x24x10

Mouse over image to zoom, click to enlarge

Description:
Encl Concept 1-Door MS GY 24x24x10

UPC:  78351037499

Part Number: CSD242410

UNSPSC: 39121324

Status:  UNKNOWN

Retail Price:  $694.00 / EA
Your Price:  $659.30 / EA


Quantity  EA

Specifications

Manufacturer Name NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
MfgPartNo CSD242410
Additional Information RoHS Compliant; Application Machine Control; Applicable Standard IEC 60529, VDE
Application Controls and Drives
Approval UL 508A, CUL, CSA C22.2
Back Panel CP2424, CP2424G
Base Price 0.0000
Body Thickness Imperial 16 ga
Brand Name CONCEPT
Catalog Number CSD242410
Color Gray;ANSI 61 Gray
Color Code ANSI 61
Commerce Sector Construction Materials
Commodity Code 36160
Commodity Description Nema Types 4 & 12 Metallic Enclosures, Boxes, Cabinets
Concept Panel CP2424
Conductive Concept Panel CP2424G
CountryOfOrigin US
Cover Type Hinged with Removable Pin, Foam Gasketed, Quarter Turn Latch
DDCATEGORY 1962
Depth 10;10 Inch
Depth Imperial 10 in
Depth Metric 254 mm
Directory CIS
Door Thickness Imperial 14 ga
Enclosure NEMA 4/12/13, IP66
Families 1962
Family Description Nema Types 4 & 12 Metallic Enclosures, Boxes, Cabinets
Finish Powder Coated;Textured Polyester Powder Coated
Height 24;24 Inch
Height Imperial 24 in
Height Metric 610 mm
IP Rating IP66
Image Location * Image
Industry ELX
InvoiceDescription Wall-Mount Type 4,12 Enclosure;WALL-MOUNT ENCL
Item Number 37499
Latch Quantity 2
Latch Style Quarter-turn
Latch Type Quarter-Turn
Long Description WALL MOUNT ENCLOSURE, 1-DOOR TYPE; MILD STEEL MATERIAL; TEXTURED POLYESTER POWDER COATED FINISH; ANSI 61 GRAY COLOR; 24 INCH; 24 INCH; 10 INCH; UL 508A, CUL, CSA C22.2 APPROVAL; WALL MOUNTING; NEMA 4/12/13, IP66 ENCLOSURE
MSDS Form Number *
Material Steel;Mild Steel
Material Specification 14 Gauge (Door), 16 Gauge (Body)
Model CW1
Modification Services Yes
Mounting Wall
Mounting Imperial 22.50 x 22.50 in
NEMA Rating 12
Noun *
Panel Size Imperial 22.20 x 22.20 in
Panel Size Metric 564 x 564 mm
Product Description Encl Concept 1-Door MS GY 24x24x10
Product Family Concept
Product Keywords WEBREADY
Product Name Electrical general purpose enclosure
ProductLine HOFF
Protection Rating NEMA Type 12
Size 24.00x24.00x10.00 in
Type Mild Steel Wall Mounted Industrial Enclosures;1-Door
Type Number Type 4
UNSPSC 39121324
UPC 78351037499
Vendor Name NVENT HOFFMAN
Vendor Number 783510
Vendor Short Name HOFF
Weight Imperial 44 lb
Width 24;24 Inch
Width Imperial 24 in
Width Metric 610 mm

Resources

CatalogNumber CSD242410
Full Image
MfrProductUrl

Package Information

SellPkgQty 1
