HOFF N280416G050

AC SpCl Nrw LtGY MS 4000BTU 115V

Page Loading...
NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
AC SpCl Nrw LtGY MS 4000BTU 115V

Mouse over image to zoom, click to enlarge

Description:
AC SpCl Nrw LtGY MS 4000BTU 115V

UPC:  78351021916

Part Number: N280416G050

UNSPSC: 40101701

Status:  UNKNOWN

Retail Price:  $4,868.00 / EA
Log In for Pricing



Specifications

Manufacturer Name NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
MfgPartNo N280416G050
Additional Information RoHS Compliant; Application Indoor, Industrial Automation, Package Handling Equipment, Security and Defense System
Ambient Temperature Imperial -40-125 F
Application Controls and Drives;Power Distribution
Approval UL, CUL, CE
Catalog Number N280416G050
Color Gray
Color Code RAL 7035
Commerce Sector Construction Materials
Commodity Code 36810
Commodity Description Enclosure Air Conditioners
Connection Type Terminal Block
Cooling Capacity 3800/4000 BTU/Hour
Corrosion Resistant No
CountryOfOrigin MX
Current Rating 10.6/10 Amp
DDCATEGORY 1986
Depth Imperial 14 in
Depth Metric 356 mm
Directory CIS
Enclosure NEMA 12, IP54 (Internal Loop), IP34 (External Loop)
Enclosure Finish RAL 7035 Light Gray Semi-Textured Powder Coated Paint
Enclosure Material Galvanized Sheet Metal
Families 1986
Family Description Enclosure Air Conditioners
Finish Powder Coated
Frequency Rating 50/60 Hertz
Height Imperial 28 in
Height Metric 711 mm
Image Location * Image
Industry ELX
Installation Enclosure
InvoiceDescription 4000BTU 115V;115V STL AIR COND
Item Number 21916
Long Description SEALED ENCLOSURE COOLING AIR CONDITIONER, 12 INCH WIDTH X 8.4 INCH DEPTH X 22.14 INCH HEIGHT SIZE; 50/60 HERTZ FREQUENCY RATING; TERMINAL BLOCK CONNECTION TYPE; ENCLOSURE INSTALLATION; GALVANIZED SHEET METAL ENCLOSURE MATERIAL; 3 PHASE(S)
MSDS Form Number *
Material Mild Steel
Max Current 11.2 A
Mechanical Advantage Galvanized Sheet Metal Standard (Optional: Stainless Steel)
Model N28, MCLG
Mounting Side wall
NEMA Rating 4 Watertight
Nominal Capacity Btu H 4,000 Btu/h
Nominal Capacity Watts 1,172 W
Nominal Voltage 115 V
Noun *
Number Of Phases 1;3
Operating Temperature -40-125;-40 to 131 Deg F
Operating Temperature Imperial -40-125 F
Operating Temperature Metric -40-52 C
Outdoor Installation Yes |
Power Rating 1039/1191 Watt
Product Description AC SpCl Nrw LtGY MS 4000BTU 115V
Product Family SpectraCool
Product Keywords WEBREADY
Product Name Air conditioners
ProductLine HOFF
Protection Rating NEMA Type 4
Refrigerant R513A
Remote Access Control No
Size 12 Inch Width x 8.4 Inch Depth x 22.14 Inch Height
Temperature Control Type Thermostat
Thickness Imperial 18 ga
Type Air Conditioners
UNSPSC 40101701
UPC 78351021916
Vendor Name NVENT HOFFMAN
Vendor Number 783510
Vendor Short Name HOFF
Voltage AC 100-120 V
Voltage Rating 100 - 120 VAC;110/115 Volt AC
WEIGHT 84 Pound
Weight Imperial 87 lb
Weight Metric 38 kg
Width Imperial 11.5 in
Width Metric 292 mm
