| Manufacturer Name | NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC |
| MfgPartNo | PST566 |
| Additional Information | Applicable Standard IEC 60529; ROHS Compliant |
| Application | Controls and Drives |
| Approval | UL 508A, CUL, CSA C22.2 |
| Base Price | 0.0000 |
| Brand Name | ProLine |
| Catalog Number | PST566 |
| Color | LtGray |
| Color Code | RAL 7035 |
| Commerce Sector | Construction Materials |
| Commodity Code | 57240 |
| Commodity Description | Enclosures & Cabinets |
| CountryOfOrigin | US |
| DDCATEGORY | 1154 |
| Depth | 23.62 |
| Depth Imperial | 23.62 in |
| Depth Metric | 600 mm |
| Directory | CIS |
| Enclosure | NEMA 12, IP55 |
| Families | 1154 |
| Family Description | Enclosures & Cabinets |
| Finish | Powder Coated;RAL 7035 Textured Light Gray Polyester Powder Painted |
| Front Opening Imperial | 17.31 x 21.11 in |
| Front Opening Metric | 440 x 536 mm |
| Height | 19.69 |
| Height Imperial | 19.69 in |
| Height Metric | 500 mm |
| IP Rating | IP55 |
| Image Location | * Image |
| Industry | ELX |
| Internal Mounting Imperial | 12.8 in |
| Internal Mounting Metric | 325 mm |
| InvoiceDescription | Sloped Top;SLOPED TOP |
| Item Number | 36469 |
| Long Description | OPERATOR INTERFACE ENCLOSURE, 14 GAUGE STEEL MATERIAL; 23.62 INCH W X 23.62 INCH D X 19.69 INCH H SIZE; RAL 7035 TEXTURED LIGHT GRAY POLYESTER POWDER PAINTED FINISH; OPERATOR INTERFACE DEVICE, CRT MONITOR USED ON; UL 508A, CUL, CSA C22.2 APPROVAL |
| MSDS Form Number | * |
| Material | Steel;14 Gauge Steel |
| Model | P9 |
| Modification Services | Yes |
| Mounting | Pedestal/Pendant |
| Nominal Dimensions Metric | 500 x 600 x 600 mm |
| Noun | * |
| Product Description | Sloped Top |
| Product Family | ProLine |
| Product Keywords | WEBREADY |
| Product Name | Electrical operator interface unit enclosure |
| ProductLine | HOFF |
| Protection Rating | IP55 |
| Rear Opening Imperial | 17.13 x 21.11 in |
| Rear Opening Metric | 435 x 536 mm |
| Size | 500x600x600mm;23.62 Inch W x 23.62 Inch D x 19.69 Inch H |
| Thickness Imperial | 14 ga |
| Thickness Metric | 1.9 mm |
| Type | HMI Enclosure Systems |
| Type Number | Type 12 |
| UNSPSC | 39121325 |
| UPC | 78351036469 |
| Used On | Operator Interface Device, CRT Monitor |
| Vendor Name | NVENT HOFFMAN |
| Vendor Number | 783510 |
| Vendor Short Name | HOFF |
| Weight Imperial | 46.72 lb |
| Width | 23.62 |
| Width Imperial | 23.62 in |
| Width Metric | 600 mm |
