HOFF T200226G100

AC SIDE 230V 50/60HZ 2000BTU

Page Loading...
NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
AC SIDE 230V 50/60HZ 2000BTU

Mouse over image to zoom, click to enlarge

Description:
AC SIDE 230V 50/60HZ 2000BTU

UPC:  78351016295

Part Number: T200226G100

UNSPSC: 40101701

Status:  UNKNOWN

Retail Price:  $5,678.00 / EA
Your Price:  $4,712.74 / EA


Quantity  EA

Specifications

Manufacturer Name NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC
MfgPartNo T200226G100
Additional Information RoHS/Reach Compliant; Refrigerant Type R134A; Sound Level 66 Decibel; Application Outdoor, Industrial Automation, Telecommunications Equipment, Package Handling Equipment, Security and Defense System; Includes Mounting Hardware, Gasket and User Manual; Ex
Amperage Rating 3.5 A
Application Controls and Drives;Power Distribution
Approval UL, CUL, CE, EAC
BTU Rating 2,000
Base Price 0.0000
Catalog Number T200226G100
Color Gray
Color Code RAL 7035
Commerce Sector Construction Materials
Commodity Code 36810
Commodity Description Enclosure Air Conditioners
Connection Type 6 Foot Cord with NEMA 6-15 Plug
Cooling Capacity 1800/2000 BTU per Hour
CountryOfOrigin US
Current Rating 3.5 Amp
DDCATEGORY 1986
Depth Imperial 9.9 in
Depth Metric 251 mm
Directory CIS
Enclosure NEMA 3R/4/12
Enclosure Finish RAL 7035 Light Gray Semi Textured Powder Coated Paint
Enclosure Material Galvanized Sheet Metal
Families 1986
Family Description Enclosure Air Conditioners
Finish Powder Coated
Frequency Rating 50/60 Hertz
Frequency Rating Maximum 60 Hz
Frequency Rating Minimum 50 Hz
Height Imperial 20 in
Height Metric 508 mm
Image Location * Image
Industry ELX
Installation Enclosure
InvoiceDescription AC SIDE 230V 50/60HZ 2000BTU;230V 50/60HZ A/C
Item Number 16295
Long Description SEALED ENCLOSURE COOLING AIR CONDITIONER, 10 INCH WIDTH X 9.9 INCH DEPTH X 20 INCH HEIGHT SIZE; 50/60 HERTZ FREQUENCY RATING; 6 FOOT CORD WITH NEMA 6-15 PLUG CONNECTION TYPE; ENCLOSURE INSTALLATION; GALVANIZED SHEET METAL ENCLOSURE MATERIAL
MSDS Form Number *
Material Mild Steel
Max Current 3.5 A
Model T20, MCL
NEMA Rating 4 Watertight
Nominal Capacity Btu H 2,000 Btu/h
Nominal Capacity Watts 586 W
Nominal Voltage 230 V
Noun *
Number Of Phases 1
Operating Temperature 131 Deg F @ 60 Hz;-40 to 131 Deg F
Operating Temperature Imperial -40-131 F
Operating Temperature Metric -40-55 C
Phase 1
Power Rating 805 Watt
Product Description AC SIDE 230V 50/60HZ 2000BTU
Product Family T-Series
Product Keywords WEBREADY
Product Name Air conditioners
ProductLine HOFF
Protection Rating NEMA Type 4
Remote Access Control No
Size 10 Inch Width x 9.9 Inch Depth x 20 Inch Height
Temperature Control Type Thermostat
Thickness Imperial 18 ga
Type Air Conditioners
UNSPSC 40101701
UPC 78351016295
Vendor Name NVENT HOFFMAN
Vendor Number 783510
Vendor Short Name HOFF
Voltage AC 200-250 V
Voltage Rating 230 V;230 Volt AC
WEIGHT 56 Pound
Weight Imperial 47.1 lb
Weight Metric 25 kg
Width Imperial 10 in
Width Metric 254 mm

Resources

CatalogNumber T200226G100
Full Image
MfrProductUrl

Package Information

SellPkgQty 1
