| Manufacturer Name | NVENT (HOFFMAN)/HOFFMAN ENCLOSURES INC |
| MfgPartNo | WS202008SS |
| Additional Information | RoHS Compliant; Applicable Standard IEC 60529 |
| Application | Corrosive Environments; Hygienic Environments; Controls and Drives |
| Approval | UL 508A, CUL, CSA C22.2, NSF 169 |
| Back Panel | A20P20, A20P20G, A20P20SS6 |
| Base Price | 0.0000 |
| Brand Name | nVent HOFFMAN;WaterShed |
| Catalog Number | WS202008SS |
| Color | Unpainted |
| Commerce Sector | Construction Materials |
| Commodity Code | 36150 |
| Commodity Description | Nema Types 4 & 4x Metallic Enclosures, Boxes, Cabinets |
| Conductive Panel | A20P20G |
| CountryOfOrigin | US |
| Cover Type | Bullet Hinged, Foam Gasketed, Self-Grounding Quarter Turn Latch |
| DDCATEGORY | 1961 |
| Depth | 8;8 Inch |
| Directory | CIS |
| Enclosure | NEMA 4/4X/12, IP66 |
| Families | 1961 |
| Family Description | Nema Types 4 & 4x Metallic Enclosures, Boxes, Cabinets |
| Finish | Brushed #4;#4 Brushed Exterior |
| Height | 20 in;20 Inch |
| IP Rating | IP66 |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | 20x20x8;20X20X8IN SS ENCL |
| Item Number | 13111 |
| Latch Quantity | 2 |
| Long Description | WALL MOUNT ENCLOSURE, 1-DOOR TYPE; 304 STAINLESS STEEL MATERIAL; #4 BRUSHED EXTERIOR FINISH; 20 INCH; 20 INCH; 8 INCH; UL 508A, CUL, CSA C22.2, NSF 169 APPROVAL; WALL MOUNTING; NEMA 4/4X/12, IP66 ENCLOSURE |
| MSDS Form Number | * |
| Material | 304 Stainless Steel |
| Material Specification | 14 Gauge |
| Model | WS1 |
| Modification Services | Yes |
| Mounting | Wall |
| NEMA Rating | 4X Watertight, corrosion-resistant |
| Noun | * |
| Panel | A20P20 |
| Product Description | 20x20x8 |
| Product Family | WaterShed |
| Product Keywords | WEBREADY |
| Product Name | Electrical general purpose enclosure |
| ProductLine | HOFF |
| Protection Rating | NEMA Type 12 |
| Size | 20.00x20.00x8.00 in |
| Stainless Steel Panel | A20P20SS6 |
| Sub Brand | WaterShed |
| Thickness Imperial | 14 ga |
| Thickness Metric | 2 mm |
| Type | Stainless Steel Wall Mounted Industrial Enclosures;1-Door |
| Type Number | Type 3R |
| UNSPSC | 39121324 |
| UPC | 78351013111 |
| Vendor Name | NVENT HOFFMAN |
| Vendor Number | 783510 |
| Vendor Short Name | HOFF |
| Weight Imperial | 41 lb |
| Width | 20;20 Inch |
