| Manufacturer Name | HUBBELL WIRING DEVICES/KELLEMS |
| MfgPartNo | GFP100C15WM |
| Additional Information | Trip Level 4 to 6 Milliamp; Housing Material High Impact UV Stabilized PVC; Temperature Rating -30 to 66 Deg C; Applicable Standard NEC, CEC |
| Amperage Rating | 15 A |
| Application | Line Cord with Male/Female Ends |
| Approval | UL 943, CSA |
| Base Price | 0.0000 |
| Brand ID | WIRING DEVICE-KELLEMS |
| Brand Name | Hubbell Wiring Device-Kellems;Circuit Guard[R] |
| Catalog Number | GFP100C15WM |
| Color | Black |
| Commerce Sector | Construction Materials |
| Commodity Code | 51800 |
| Commodity Description | Miscellaneous Wiring Devices |
| Conductor Material | Copper |
| Conductor Size | #14 AWG |
| Construction | Fabricated |
| Cord Type | 14/3 SJTW-A (UL), SJTW (CSA) |
| CountryOfOrigin | CN |
| Current Amperage Rating | 15 A |
| Current Rating | 15 A |
| DDCATEGORY | 579 |
| Description Long | Power Protection Products, GFCI Linecords, Commercial, Manual Set, 15A, 120V AC, 5-15R, 100' Cord Length, 4-6 mA Trip Level, Black and Yellow. |
| Description Short | Power Protection Products, GFCI Linecords, Commercial, Manual Set, 15A, 120V AC, 5-15R, 100' Cord Length, 4-6 mA Trip Level, Black and Yellow |
| Directory | CIS |
| EU RoHS Indicator | No |
| FEATURES Bullets | Unit must be reset by pushing the reset button upon plug in and after loss of primary power;After a ground fault condition, unit must be reset by pushing the reset button;Ideal for applications where operator injury might occur if equipment were to restart after a power failure |
| FV Voltage Rating Description | 120 VAC | |
| Families | 579 |
| Family Description | Miscellaneous Wiring Devices |
| Image Location | * Image |
| Industry | ELX |
| Insulation Material | Elastomer |
| InvoiceDescription | GFCI CORDSET, 15A 120V, 100';15A 120V 100 GFCI |
| Item Number | 82933 |
| Item Type | Straight Blade |
| Jacket Material | PVC |
| Length | 100 ft;100 Foot |
| Long Description | GROUND FAULT CIRCUIT INTERRUPTER, 100 FOOT; UL 943, CSA APPROVAL; 14/3 SJTW-A (UL), SJTW (CSA) CORD TYPE; STRAIGHT BLADE GFCI PLUG TYPE; 120 VOLT AC AT 60 HERTZ 15 AMP, NEMA 5-15R OUTLET RATING; 120 VOLT AC AT 60 HERTZ 15 AMP, NEMA 5-15P PLUG RATING |
| MSDS Form Number | * |
| Material Insulation | Elastomer |
| Material Jacket | PVC |
| Model | GFP |
| Noun | * |
| Number Of Conductors | 3 |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Outlet Rating | 120 Volt AC at 60 Hertz 15 Amp, NEMA 5-15R |
| Outside Diameter | 0.245 in |
| Plug Rating | 120 Volt AC at 60 Hertz 15 Amp, NEMA 5-15P |
| Plug Type | Straight Blade GFCI |
| Power Out Reset | Manual |
| Product Description | GFCI CORDSET, 15A 120V, 100' |
| Product Keywords | WEBREADY |
| Product Name | Circuit Guard Extra Heavy Duty Elastogrip Watertight Straight Blade Portable GFCI Line Cord with Manual Set, 15A, 120V AC, 100', Black |
| ProductLine | HUBW |
| Series | Extra Heavy Duty |
| Special Features | Manual Set |
| Standard | UL Listed |
| Strands | Multi |
| Sub Brand | GFCI Portable Cordsets |
| Temperature Rating | -35 Degrees C to 66 Degrees C (-30 Degrees F to 150 Degrees F) |
| Type | Line Cord |
| UNSPSC | 26121536 |
| UPC | 78358582933 |
| Vendor Name | HUBBELL WIRING DEVICE/KELLEMS |
| Vendor Number | 783585 |
| Vendor Short Name | HUBW |
| Voltage Rating | 120 VAC |
| Voltage Rating Description | 120 VAC |
| WEIGHT | 16.85 lb. |
