| Manufacturer Name | HUBBELL WIRING DEVICES/KELLEMS |
| MfgPartNo | HBL1221RKL |
| Action | Snap |
| Actuator | Cylindrical Key |
| Additional Information | Dielectric Voltage Withstand 1500 Volt AC for 1 Minute; Wire Size 14 to 10 AWG Solid/Stranded Copper; Flammability Rating UL 94V-2; Contact Material Silver Alloy; Terminal/Ground Screw Material Brass; Temperature Rating -40 to 75 Deg C |
| Amperage Rating | 20 A |
| Application | Back and Side Wired;Industrial, General Purpose |
| Approval | UL, CSA |
| Brand Name | HBL[R] |
| Catalog Number | HBL1221RKL |
| Certified Listed | TAA Compliant (All status valid till December 2024) |
| Color | Chrome;Chrome Plated (Key Guide), Red (Base) |
| Commerce Sector | Construction Materials |
| Commodity Code | 51100 |
| Commodity Description | General Purpose Switches |
| Connection | Terminal Screws |
| Contact Configuration | 2-Position |
| Contact Rating | Full Rated |
| CountryOfOrigin | US |
| Current Amperage Rating | 20 A |
| Current Rating | 20 A;20 Amp |
| DDCATEGORY | 572 |
| Description Long | Switches and Lighting Controls, Industrial Grade, Barrel Key Locking Switch, General Purpose AC, Single Pole, 20A 120/277V AC, Back and Side Wired, Chrome |
| Description Short | Switches and Lighting Controls, Industrial Grade, Barrel Key Locking Switch, General Purpose AC, Single Pole, 20A 120/277V AC, Back and Side Wired, Chrome |
| Directory | CIS |
| EU RoHS Indicator | No |
| Enclosure | None |
| FEATURES Bullets | Large brass binding head screws with deep slots;Lock circuits On or Off;Strip gauge for accurate wiring |
| FV BuyAmericanCompliant | Yes |
| FV Certified Listed | TAA Compliant (All status valid till December 2024) |
| FV Current Amperage Rating | 20 A |
| FV Voltage Rating Description | 120-277 VAC |
| Families | 572 |
| Family Description | General Purpose Switches |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | SP TOG, IND GRD, 20A 120/277V, ROT LOCK;20A RED SP-TGL SW |
| Item Number | 43157 |
| Load | Inductive or Resistive |
| Lock Type | Cylindrical |
| Long Description | AC SWITCH, EXTRA HEAVY DUTY TYPE; THERMOSET (TOP/BASE) MATERIAL; 1.25 INCH WIDTH X 2.02 INCH DEPTH SIZE; CHROME PLATED (KEY GUIDE), RED (BASE) COLOR; 1-POLE OPERATION TYPE; UL, CSA APPROVAL; INDUSTRIAL, GENERAL PURPOSE APPLICATION |
| MSDS Form Number | * |
| Material | Composite;Thermoset (Top/Base) |
| Mounting | Mounting Screws |
| Noun | * |
| Operation Type | 1-Pole |
| Pallet Quantity | 3600 |
| Performance | Electrical - Dielectric Voltage - Withstands 1500V AC minimum for 1 minute;Electrical - Max. Continuous Current - 20A;Electrical - Max. Working Voltage - 277V AC;Electrical - Overload - Minimum 4.8 times rated current for 100 cycles;Electrical - Temperature Rise - 30C maximum at rated current;Environmental - Flammability - UL 94V-2;Environmental - Operating Temperature - Max. continuous: 75C, Min. continuous: -40C without impact;Mechanical - Terminal Accommodations - #14 AWG min. - #10 AWG max. solid and stranded copper wire only |
| Power Rating | 1 HP at 120 Volt AC, 2 HP at 208/240/277 Volt AC |
| Product Description | SP TOG, IND GRD, 20A 120/277V, ROT LOCK |
| Product Keywords | WEBREADY |
| Product Name | Industrial Grade, Barrel Key Locking Switch, General Purpose AC, Single Pole, 20A 120/277V AC, Back and Side Wired, Chrome |
| ProductLine | HUBW |
| Series | Extra Heavy Duty |
| Size | 4.06 in x 1.25 in x 2.02 in;1.25 Inch Width x 2.02 Inch Depth |
| Special Features | Standard Product |
| Standard | UL Listed |
| Temperature Rating | Max Continuous- 75 Degrees C, Minimum- -40 Without Impact |
| Temperature Rise Max | 30C maximum at rated current |
| Type | Locking;Extra Heavy Duty |
| UNSPSC | 39122224 |
| UPC | 78358543157 |
| Vendor Name | HUBBELL WIRING DEVICE/KELLEMS |
| Vendor Number | 783585 |
| Vendor Short Name | HUBW |
| Voltage Rating | 120-277 VAC;120/277 Volt AC |
| Voltage Rating Description | 120-277 VAC | |
| Wattage | 5540 W |
| Wiring | Back, Side |
