| Manufacturer Name | HUBBELL WIRING DEVICES/KELLEMS |
| MfgPartNo | HBL24312 |
| Additional Information | Wire Size 16 to 12 AWG Copper; Dimension 1.62 Inch Dia x 3.47 Inch W |
| Amperage Rating | 20 AMP |
| Application | Hospital Use Devices |
| Approval | UL |
| Base Price | 0.0000 |
| Brand Name | Hubbellock [R] |
| Catalog Number | HBL24312 |
| Commerce Sector | Construction Materials |
| Commodity Code | 51300 |
| Commodity Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| Configuration | 5-20P |
| Connection | Screwed Terminal |
| Cord Size | 0.32 to 0.66 Inch |
| Cord Type | All Portable |
| CountryOfOrigin | US |
| Current Rating | 20 Ampere |
| DDCATEGORY | 574 |
| Decorative Color | Metallic |
| Description Long | Hubbellock, Hospital Grade, Explosion Proof Plug, 125V, 2-Pole 3-Wire Grounding, Non NEMA, Screw Terminal, Chrome |
| Description Marketing Copy | The Hubbellock devices feature an exclusive design unlike any other in the industry. The unique design is built to provide the safest heavy duty device even in some of the harshest environments. These Hubbellock plugs and connector bodies are built with a super tough nylon housing for high impact resistance and a one of kind interior design for superior safety that Hubbell is known for. The male contacts are molded into the nose for damage resistance and completely eliminate the chance of deformity. Additionally, the plug as well as the connector retains power mechanical cord grips that not only secure the cable but also clamp down on the conductors in order to provide unrivaled strain relief. Inside the connector is Hubbell's unique safety design. With unparalleled box terminations the connector interior holds a spring-loaded safety shutter to provide the ultimate arc protection. Furthermore the exceptional heat and impact resistance is maintained by the thermoplastic interior contributing to a longer lasting device. In all, the one of a kind function of the Hubbellock devices provide a safe and dependable performance in the most demanding applications. |
| Description Short | Hubbellock, Hospital Grade, Explosion Proof Plug |
| Directory | CIS |
| EU RoHS Indicator | Contact Manufacturer |
| Environmental Conditions | Indoor Dry unless protected by additional means |
| FEATURES Bullets | For Hospital Use Only |
| Families | 574 |
| Family Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| Ground Type | Grounding |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | H/LOCK PLUG, 20A 125V, EXP PROOF;EX-PRF PLUG 3W20A125V |
| Item Number | 01574 |
| Long Description | EXPLOSIONPROOF PLUG, EPOXY MATERIAL; 5-20P CONFIGURATION; 3 WIRE(S); UL APPROVAL; 125 VAC VOLTAGE RATING; 20 AMPERE CURRENT RATING; GROUNDING; 2 POLE(S); 0.32 TO 0.66 INCH CORD SIZE; HUBBELLOCK [R] BRAND; WIRE SIZE 16 TO 12 AWG COPPER |
| MSDS Form Number | * |
| Material | Composite;Epoxy |
| Model | HBL243 |
| Mounting | Cord |
| NEMA Rating | Non-NEMA |
| Noun | * |
| Number Of Poles | 2 |
| Number Of Wires | 3 |
| Phase | 1 |
| Product Description | H/LOCK PLUG, 20A 125V, EXP PROOF |
| Product Keywords | WEBREADY |
| Product Name | Locking Devices, Hubbellock, HospitalUse, Explosion Proof Plug, 125V, 2-Pole 3-Wire Grounding, Non NEMA, Screw Terminal, Chrome |
| ProductLine | HUBW |
| Size | Standard Sized |
| Special Features | Explosion Proof |
| Standard | UL 498 |
| Type | Male Plug |
| UNSPSC | 39121402 |
| UPC | 78358501574 |
| Vendor Name | HUBBELL WIRING DEVICE/KELLEMS |
| Vendor Number | 783585 |
| Vendor Short Name | HUBW |
| Voltage Rating | 125;125 VAC |
| Wattage | 2000 W |
| Wire Size | #12 |
