| Manufacturer Name | HUBBELL WIRING DEVICES/KELLEMS |
| MfgPartNo | HBL2723 |
| Additional Information | Dimension 3.86 Inch Length x 2.33 Inch Width x 2.33 Inch Height; Wire Size 16 to 8 AWG Stranded Copper; Terminal Type #10-32 TPI (Phillips/Slotted/Robertson) Screw; Power Rating 3 HP; Dielectric Voltage 2000 Volt; Number of Phases 3; Operating Temperature |
| Amperage Rating | 30 A |
| Application | Heavy Duty Industrial |
| Approval | UL, CSA |
| Base Price | 0.0000 |
| Brand ID | WIRING DEVICE-KELLEMS |
| Brand Name | Hubbell Wiring Device-Kellems;Twist-Lock [R], Insulgrip [R] |
| Cable Range | 0.350 - 1.150 in |
| Carton Quantity | 30 |
| Catalog Number | HBL2723 |
| Color | Black/White |
| Commerce Sector | Construction Materials |
| Commodity Code | 51300 |
| Commodity Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| Conductor Range | #12AWG to #8AWG |
| Configuration | L15-30R |
| Connection | Pressure Screw Terminal |
| Cord Diameter | 0.350-1.150 in |
| Cord Range | "0.350""-1.150"" (9-29)" |
| Cord Size | 0.35 to 1.15 Inch |
| CountryOfOrigin | PR |
| Current Amperage Rating | 30 A |
| Current Rating | 30 A;30 Amp |
| DDCATEGORY | 574 |
| Directory | CIS |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| FEATURES Bullets | Superior cord grip design protects terminations from excess strain.;Clear, funnel shaped wire entry for ease of termination.;Integral dust shield protects wiring chamber from dust or contaminants. |
| FV Current Amperage Rating | 30 A |
| FV Voltage Rating Description | 3 Phase 250 VAC |
| Families | 574 |
| Family Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| Ground Type | Grounding |
| Image Location | * Image |
| Industry | ELX |
| Insulation | Insulated Body |
| InvoiceDescription | LKG CONN, 30A 3P 250V, L15-30R, B/W;GRD LKG CONN-N L15-30R |
| Item Number | 03925 |
| Item Type | 30A Grounding Insulgrip Connector |
| Long Description | LOCKING DEVICE CONNECTOR, POLARIZED TYPE; NYLON (HOUSING), CLEAR POLYCARBONATE (TERMINAL RETAINER), BRASS (CONTACT/TERMINAL SCREW), NICKEL PLATED COLD ROLLED STEEL (TERMINAL CLAMP), NICKEL PLATED STEEL (ASSEMBLY SCREW) MATERIAL; BLACK/WHITE COLOR |
| MSDS Form Number | * |
| Material | Nylon;Nylon (Housing), Clear Polycarbonate (Terminal Retainer), Brass (Contact/Terminal Screw), Nickel Plated Cold Rolled Steel (Terminal Clamp), Nickel Plated Steel (Assembly Screw) |
| Material Mounting Hardware | Cord Mounted |
| Mounting | Cord Mounted |
| NEMA Rating | L15-30R |
| Noun | * |
| Number Of Conductors | 4-Wire Grounding |
| Number Of Poles | 3 |
| Number Of Wires | 4 |
| OEM Brand Name | Hubbell Wiring Device-Kellems | |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - HB or better per UL94 or CSA 22.2 No. 0.6;Environmental - Operating Temperatures - Maximum Continuous 75C Minimum -40C (w/o impact);Mechanical - Terminal Accommodation - #16 AWG - #8 AWG stranded copper wire only.;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 |
| Product Description | LKG CONN, 30A 3P 250V, L15-30R, B/W |
| Product Keywords | WEBREADY |
| Product Name | Locking Devices, Twist-Lock, Industrial, Female Connector Body, 30A 3-Phase Delta 250V AC, 3-Pole 4-Wire Grounding, L15-30R, Screw Terminal and White |
| ProductLine | HUBW |
| Size | 2.33 in x 2.33 in x 3.86 in |
| Special Features | Standard Product |
| Standard | Certified to CSA C22.2 No.42;Fed.Spec. W-C-596;Listed to UL 498 |
| Sub Brand | Twist-Lock |
| Temperature Rating | Maximum Continuous: 75 C; Minimum Continuous: -40 C w/o impact, -25 with impact. |
| Type | Connector Body;Polarized |
| UNSPSC | 39121421 |
| UPC | 78358503925 |
| Vendor Name | HUBBELL WIRING DEVICE/KELLEMS |
| Vendor Number | 783585 |
| Vendor Short Name | HUBW |
| Voltage Rating | 3 Phase 250 VAC;250 Volt AC |
