| Manufacturer Name | HUBBELL WIRING DEVICES/KELLEMS |
| MfgPartNo | HBL29W78 |
| Additional Information | Number of Phases 3; Enclosure Rating 4/4X/12/6/6P; Contact Material Nickel Plated Brass; Temperature Rating -40 to 60 Deg C; Applicable Standard WD-1/6, ANSI |
| Amperage Rating | 30 A |
| Application | Industrial/Commercial |
| Approval | UL 498, CSA C22.2 |
| Brand Name | Twist-Lock[R] |
| Catalog Number | HBL29W78 |
| Color | Yellow |
| Commerce Sector | Construction Materials |
| Commodity Code | 51300 |
| Commodity Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| Conductor Range | #14AWG to #10AWG |
| Configuration | L18-30R |
| Connection | Terminal Screws |
| Constructional Feature | Corrosion Resistant, Water Tight |
| Cord Diameter | 0.385-1.050 in |
| Cord Size | 0.375 to 1 Inch Diameter |
| CountryOfOrigin | PR |
| Current Amperage Rating | 30 A |
| Current Rating | 30 Amp |
| DDCATEGORY | 574 |
| Description Long | Watertight Devices, Twist-Lock Connector, 30A, 3 Phase WYE 120/208V AC, 4 Pole, 4 Wire, Thermoplastic elastomer, NEMA L18-30R, Yellow |
| Description Short | WT CONN,NEMA L18-30R,30A,120/208 3PY YEL |
| Directory | CIS |
| EU RoHS Indicator | Contact Manufacturer |
| Environmental Conditions | Water Tight |
| FEATURES Bullets | Smooth body design minimizes collection points simplifying the wash down process;Stainless steel hardware and corrosion-resistant connection points;Strain relief nut always seals on the body, minimizing debris collection |
| FV Current Amperage Rating | 30 A |
| FV Voltage Rating Description | 3-Phase Y 120/208 VAC |
| Families | 574 |
| Family Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| Image Location | * Image |
| Industry | ELX |
| Insulation | Insulated Body |
| InvoiceDescription | WT CONN,NEMA L18-30R,30A,120/208 3PY YEL;30A/208V WT CONN |
| Item Number | 45648 |
| Long Description | CONNECTOR, POLARIZED TYPE; THERMOPLASTIC ELASTOMER MATERIAL; YELLOW COLOR; L18-30R CONFIGURATION; 4 WIRE(S); UL 498, CSA C22.2 APPROVAL; 120/208 VOLT AC VOLTAGE RATING; 30 AMP CURRENT RATING; 4 POLE(S); CORROSION RESISTANT, WATER TIGHT |
| MSDS Form Number | * |
| Material | Composite;Thermoplastic Elastomer |
| Mounting | Cord |
| NEMA Rating | L18-30R |
| Noun | * |
| Number Of Conductors | 5 |
| Number Of Poles | 4-Pole;4 |
| Number Of Wires | 4 |
| Performance | "Electrical - Current Interrupting - Rated for current interruption per UL498;Electrical - Dielectric Voltage - 2500V AC;Electrical - Max Working Voltage - As marked;Electrical - Temperature Rise - 30C max per UL498 at rated current;Environmental - Moisture Resistance - UL Listed 4, 4X, 12, 6, 6P;Environmental - Operating Temperatures - -40C (without impact) to +60C continuous;Environmental - UV resistance - All exposed materials are UV stabilized;Mechanical - Cord Accommodation - 0.375""-1.000"" (9.5-25.4)" |
| Product Description | WT CONN,NEMA L18-30R,30A,120/208 3PY YEL |
| Product Keywords | WEBREADY |
| Product Name | Watertight Devices, Twist-Lock Connector, 30A, 3 Phase WYE 120/208V AC, 4 Pole, 4 Wire, Thermoplastic elastomer, NEMA L18-30R, Yellow |
| ProductLine | HUBW |
| Size | 2.77 in x 2.77 in x 5.67 in |
| Special Features | Water-Tight |
| Standard | Meets NEMA WD-1, WD-6 And ANSI Standards |
| Standards RoHS Compliance Status | CM |
| Temperature Rating Maximum | 167.00000 F |
| Type | Connector Body;Polarized |
| UNSPSC | 39121421 |
| UPC | 78358545648 |
| Vendor Name | HUBBELL WIRING DEVICE/KELLEMS |
| Vendor Number | 783585 |
| Vendor Short Name | HUBW |
| Voltage Rating | 3-Phase Y 120/208;120/208 Volt AC |
| Voltage Rating Description | 3-Phase Y 120/208 VAC |
