| Manufacturer Name | HUBBELL WIRING DEVICES/KELLEMS |
| MfgPartNo | HBL560C9W |
| Additional Information | Wire Size 8 to 2 AWG; Enclosure Rating IP67; Temperature Rating -40 to 75 Deg C |
| Amperage Rating | 60 A |
| Application | High Ampacity Connections |
| Approval | UL 94/1682, CSA C22.2 |
| Base Price | 0.0000 |
| Brand ID | WIRING DEVICE-KELLEMS |
| Brand Name | Hubbell Wiring Device-Kellems |
| Carton Quantity | 10 |
| Catalog Number | HBL560C9W |
| Color | Blue |
| Commerce Sector | Construction Materials |
| Commodity Code | 51500 |
| Commodity Description | Pin & Sleeve Devices |
| Conductor Range | #8 AWG to #2 AWG |
| Connection | Pressure Screw Terminal |
| Constructional Feature | Water Tight |
| CountryOfOrigin | PR |
| Current Amperage Rating | 60 A |
| Current Rating | 60 A;60 Amp |
| DDCATEGORY | 576 |
| Description Short | Heavy Duty Products, IEC Pin and Sleeve Devices, Industrial Grade, Female, Connector Body, 60A 3-Phase Wye 120/208V AC, 4-Pole 5-Wire Grounding, Terminal Screws, Blue, Watertight |
| Directory | CIS |
| EU RoHS Indicator | Yes | |
| Environmental Conditions | Watertight |
| FEATURES Bullets | Self-closing gasketed cover;Color coded housings for easy identification;Super tough insulated non-metallic housing |
| FV Current Amperage Rating | 60 A |
| FV Voltage Rating Description | 3 Phase Y 120/208 VAC |
| Families | 576 |
| Family Description | Pin & Sleeve Devices |
| Grounding Style | Grounding |
| Image Location | * Image |
| Industry | ELX |
| Insulation | Insulated Body |
| InvoiceDescription | PS,IEC, CONN,4P5W,60/63A 120/208V,4X/69K;CONN-4P5W120/208V |
| Item Number | 40567 |
| Item Type | Standard |
| Long Description | CONNECTOR, PBT (HOUSING) MATERIAL; 0.5 INCH MIN. CABLE OUTER DIAMETER; 1.45 INCH MAX. CABLE OUTER DIAMETER; 5 WIRE(S); UL 94/1682, CSA C22.2 APPROVAL; 120/208 VOLT AC STAR 3-PHASE VOLTAGE RATING; 60 AMP CURRENT RATING; 4 POLE(S); WATER TIGHT |
| MSDS Form Number | * |
| Material | Composite;PBT (Housing) |
| Material Mounting Hardware | Cord Mounted |
| Maximum Cable Outer Diameter | 1.45 Inch |
| Minimum Cable Outer Diameter | 0.5 Inch |
| Mounting | Cord Mounted |
| NEMA Rating | Non-NEMA |
| Noun | * |
| Number Of Conductors | 5-Wire Grounding |
| Number Of Poles | 4 |
| Number Of Wires | 5 |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstand 3000V AC;Electrical - Max. Working Voltage - 600V RMS;Environmental - Flammability - HB or better per UL 94 or CSA C22.2 No. 0.17;Environmental - Ingress Protection - IP67 Suitability;Environmental - Moisture Resistance - Watertight per IEC 60309-1;Environmental - Operating Temperatures - Maximum Continuous 75C;Minimum - 40C w/o impact;Mechanical - Impact Resistance - Per CSA C22.2 No. 182.1 / UL1682;Mechanical - Product Identification - Ratings are a permanent part of the device housing;Mechanical - Terminal Identification - Terminals identified in accordance with North American and IEC conventions |
| Product Description | PS,IEC, CONN,4P5W,60/63A 120/208V,4X/69K |
| Product Keywords | WEBREADY |
| Product Name | Heavy Duty Products, IEC Pin and Sleeve Devices, Industrial Grade, Female, Connector Body, 60A 3-Phase Wye 120/208V AC, Watertight |
| ProductLine | HUBW |
| Series | HBL Heavy Duty |
| Size | Standard |
| Special Features | Watertight |
| Standard | CSA Certified File LR280C;UL Classified to IEC 60309-1 IEC 60309-2;UL Listed, File E146033 |
| Sub Brand | Pin and Sleeve |
| Temperature Rating | Maximum Continuous: 75 C; Minimum Continuous: -40 C w/o impact, -25 with impact. |
| Type | Watertight Connector Body |
| UNSPSC | 39121421 |
| UPC | 78358540567 |
| Vendor Name | HUBBELL WIRING DEVICE/KELLEMS |
| Vendor Number | 783585 |
| Vendor Short Name | HUBW |
| Voltage Rating | 3 Phase Y 120/208 VAC;120/208 Volt AC Star 3-Phase |
