| Manufacturer Name | HUBBELL WIRING DEVICES/KELLEMS |
| MfgPartNo | HBL5652 |
| Additional Information | Contact/Strap Material Brass; Operating Temperature -40 to 75 Deg C |
| Amperage Rating | 15 A |
| Application | Extra Heavy Duty |
| Approval | UL 498, CSA 22.2 |
| Base Price | 0.0000 |
| Brand Name | HBL[R] |
| Catalog Number | HBL5652 |
| Certified Listed | TAA Compliant (All status valid till December 2024) |
| Color | Brown |
| Commerce Sector | Construction Materials |
| Commodity Code | 51200 |
| Commodity Description | Receptacles & Surge Protectors |
| Configuration | 6-15R |
| Connection | Side Wired Only |
| Constructional Feature | Impact Resistant |
| CountryOfOrigin | US |
| Current Amperage Rating | 15 A |
| Current Rating | 15 A;15 Ampere |
| DDCATEGORY | 573 |
| Description Long | Straight Blade Devices, Receptacles, Duplex, Specification Grade, 2-Pole 3-Wire Grounding, 15A 250V, 6-15R, Brown, Single Pack |
| Description Short | Straight Blade Devices, Receptacles, Duplex, Specification Grade, 2-Pole 3-Wire Grounding, 15A 250V, 6-15R, Brown, Single Pack |
| Dielectric Strength | Withstands 2,000V minimum |
| Directory | CIS |
| EU RoHS Indicator | Yes |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| FEATURES Bullets | One-piece brass integral ground strap;Unique bypass contact design |
| FV BuyAmericanCompliant | Yes |
| FV Certified Listed | TAA Compliant (All status valid till December 2024) |
| FV Current Amperage Rating | 15 A |
| FV Voltage Rating Description | 250 V |
| Families | 573 |
| Family Color | Brown |
| Family Description | Receptacles & Surge Protectors |
| Grade | Extra Heavy-Duty, Specification |
| Ground Type | Grounding |
| Horsepower Maximum | 1.5 |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | DUP RCPT, IND GRD, 15A 250V, 6-15R, BK;DPLX RCPT NEMA6-15R |
| Item Number | 43536 |
| Long Description | STRAIGHT BLADE DUPLEX RECEPTACLE, SINGLE TYPE; NYLON (FACE) MATERIAL; BROWN COLOR; 6-15R CONFIGURATION; 3 WIRE(S); EXTRA HEAVY-DUTY, SPECIFICATION GRADE; UL 498, CSA 22.2 APPROVAL; 250 V VOLTAGE RATING; 15 AMPERE CURRENT RATING; GROUNDING; 2 POLE(S) |
| MSDS Form Number | * |
| Material | Nylon (Face) |
| Material Mounting Hardware | Screw Mounting |
| Material Quality | Thermoplastic/Composite |
| Mounting | Screw Mount |
| NEMA Rating | 6-15R |
| Noun | * |
| Number Of Poles | 2-Pole;2 |
| Number Of Wires | 3-Wire;3 |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - UL 94 V-2 or better;Environmental - Operating Temperatures - Maximum continuous 75C minimum -40C (w/o impact);Mechanical - Product Identification - Ratings are a permanent part of the device;Mechanical - Terminal Accommodation - #14-#10 AWG copper stranded or solid conductor only;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA |
| Phase | 1 |
| Product Description | DUP RCPT, IND GRD, 15A 250V, 6-15R, BK |
| Product Keywords | WEBREADY |
| Product Name | Straight Blade Devices, Receptacles, Duplex, Specification Grade, 2-Pole 3-Wire Grounding, 15A 250V, 6-15R, Brown, Single Pack |
| ProductLine | HUBW |
| Series | Extra Heavy Duty |
| Size | 3.28 in x 1.33 in x 1.05 in |
| Special Features | Self Grounding |
| Standard | Certified to CSA 22.2, No. 42 File 285;Guide RTRT Fed Spec WC596G;NEMA WD-6 Compliant;UL Listed to UL498 File No. E2186 |
| Standards RoHS Compliance Status | CM |
| Type | Standard Duplex;Single |
| UNSPSC | 39121406 |
| UPC | 78358543536 |
| Vendor Name | HUBBELL WIRING DEVICE/KELLEMS |
| Vendor Number | 783585 |
| Vendor Short Name | HUBW |
| Voltage Rating | 250 V |
| Voltage Rating Description | 250 V | |
| Wattage | 3750 W |
| Wire Size | #14 to #10 |
| Wiring | Side |
