| Manufacturer Name | HUBBELL WIRING DEVICES/KELLEMS |
| MfgPartNo | HBL5679C |
| Additional Information | Material Nylon; Operating Temperature -40 to 75 Deg C |
| Amperage Rating | 15 A |
| Application | Heavy Duty |
| Approval | UL 498, CSA C22.2 |
| Base Price | 0.0000 |
| Brand ID | WIRING DEVICE-KELLEMS |
| Brand Name | Hubbell Wiring Device-Kellems |
| Carton Quantity | 10 |
| Catalog Number | HBL5679C |
| Color | White |
| Commerce Sector | Construction Materials |
| Commodity Code | 51200 |
| Commodity Description | Receptacles & Surge Protectors |
| Configuration | 6-15R |
| Connection | Screw Terminals |
| CountryOfOrigin | PR |
| Current Amperage Rating | 15 A |
| Current Rating | 15 A;15 Ampere |
| DDCATEGORY | 573 |
| Description Short | Straight Blade Devices, Receptacles, Commercial/Industrial Grade, 2-Pole3-Wire Grounding, 15A 250V, 6-15R, White, Single Pack. | |
| Dielectric Strength | Withstands 2,000V minimum |
| Directory | CIS |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| FEATURES Bullets | Impact resistant thermoplastic construction;Backwired terminations for ease of installation;#8-32 Multiple drive terminal screws;Mounting screws included |
| FV Current Amperage Rating | 15 A |
| FV Voltage Rating Description | 250 V |
| Families | 573 |
| Family Description | Receptacles & Surge Protectors |
| Ground Type | Grounding |
| Horsepower Maximum | 1.5 |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | FLG-RCPT, 15A 250V, 6-15P, WH;FLGD OUTLET-NEMA6-15P |
| Item Number | 17600 |
| Item Type | Flanged Single |
| Long Description | STRAIGHT BLADE FLANGED RECEPTACLE, WHITE COLOR; 6-15R CONFIGURATION; 3 WIRE(S); UL 498, CSA C22.2 APPROVAL; 250 V VOLTAGE RATING; 15 AMPERE CURRENT RATING; GROUNDING; 2 POLE(S); BACK WIRING; MATERIAL NYLON; OPERATING TEMPERATURE -40 TO 75 DEG C |
| MSDS Form Number | * |
| Material | Thermoplastic |
| Material Mounting Hardware | Screw Mounting |
| Mounting | Screw Mount |
| NEMA Rating | 6-15R |
| Noun | * |
| Number Of Poles | 2 |
| Number Of Wires | 3 |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - UL 94 V-2;Environmental - Operating Temperatures - Maximum continuous 75C minimum -40C (w/o impact);Mechanical - Product Identification - Ratings are a permanent part of the device;Mechanical - Terminal Accommodation - #18-#10 AWG copper stranded or solid conductor only;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA |
| Phase | 1 |
| Product Description | FLG-RCPT, 15A 250V, 6-15P, WH |
| Product Keywords | WEBREADY |
| Product Name | Straight Blade Devices, Receptacles, Commercial/Industrial Grade, 2-Pole3-Wire Grounding, 15A 250V, 6-15R, White, Single Pack. |
| ProductLine | HUBW |
| Series | Extra Heavy Duty |
| Size | 1.72 in x 2.56 in x 2.56 in |
| Special Features | Standard |
| Standard | Certified to CSA, C22.2, No. 42;NEMA WD-6 Compliant;UL Listed, File E2186 |
| Sub Brand | Straight Blade Devices |
| Type | Flanged Receptacle |
| UNSPSC | 39121406 |
| UPC | 78358517600 |
| Vendor Name | HUBBELL WIRING DEVICE/KELLEMS |
| Vendor Number | 783585 |
| Vendor Short Name | HUBW |
| Voltage Rating | 250 V |
| Wattage | 3,750 W |
| Wire Size | #18 AWG to #10 AWG |
| Wiring | Back |
