| Manufacturer Name | HUBBELL WIRING DEVICES/KELLEMS |
| MfgPartNo | HBL8315C |
| Additional Information | Blade Holder Material Nylon; Terminal Retainer Material PBT; Terminal Clamp Material Plated Steel; Terminal Screw Brass; Enclosure Rating IP20; Temperature Rating -40 to 75 Deg C; Applicable Standard Federal Specification W-C-596 |
| Amperage Rating | 20 A |
| Application | Hospital Grade |
| Approval | UL 498, CSA C22.2 |
| Base Price | 0.0000 |
| Brand ID | WIRING DEVICE-KELLEMS |
| Brand Name | Hubbell Wiring Device-Kellems;Insulgrip[R], VARI-SIZE[R] |
| Carton Quantity | 10 |
| Catalog Number | HBL8315C |
| Color | Black/White |
| Commerce Sector | Construction Materials |
| Commodity Code | 51300 |
| Commodity Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| Configuration | 5-20P |
| Connection | Terminal Screws |
| Cord Range | "0.230""-0.720"" (5.8-18.3)" |
| Cord Size | 0.23 to 0.72 Inch |
| Cord Type | All Portable |
| CountryOfOrigin | PR |
| Current Rating | 20 A;20 Amp |
| DDCATEGORY | 574 |
| Description Long | Straight Blade Devices, Male Plug, Insulgrip, Hospital Grade, Straight, 2-Pole 3-Wire Grounding, 20A 125V, 5-20P, Black and White, Single Pack. |
| Description Short | Straight Blade Devices, Male Plug, Insulgrip, Hospital Grade, Straight, 2-Pole 3-Wire Grounding, 20A 125V, 5-20P, Black and White, Single Pack |
| Directory | CIS |
| EU RoHS Indicator | Contact Manufacturer |
| Environmental Conditions | Indoor Dry unless protected by additional means |
| FEATURES Bullets | Beveled housing prevents snagging;Powerful, offsetting cord grips clamp on individual conductors | |
| FV Current Amperage Rating | 20 A |
| FV Voltage Rating Description | 125 V |
| Families | 574 |
| Family Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| Grade | Hospital |
| Ground Type | Grounding |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | PLUG, HG, 20A 125V, 5-20P, B/W;HOSP PLUG-NEMA5-20P |
| Item Number | 17995 |
| Item Type | Insulgrip Plug |
| Long Description | STRAIGHT BLADE PLUG, NYLON MATERIAL; BLACK/WHITE COLOR; 5-20P CONFIGURATION; 3 WIRE(S); HOSPITAL GRADE; UL 498, CSA C22.2 APPROVAL; 125 VOLT AC VOLTAGE RATING; 20 AMP CURRENT RATING; GROUNDING; 2 POLE(S); 0.23 TO 0.72 INCH CORD SIZE |
| MSDS Form Number | * |
| Material | Nylon |
| Mounting | Cord Mounted |
| NEMA Rating | 5-20P |
| Noun | * |
| Number Of Poles | 2 |
| Number Of Wires | 3 |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Phase | 1 |
| Product Description | PLUG, HG, 20A 125V, 5-20P, B/W |
| Product Keywords | WEBREADY |
| Product Name | Electrical plugs |
| ProductLine | HUBW |
| Series | Hospital Grade |
| Size | 1.97 in x 1.53 in x 1.53 in |
| Special Features | Standard Product |
| Standard | Certified to CSA, C22.2, No. 42 File 285;Fed. Spec. W-C-596;UL Listed to UL498 File No. E2186 |
| Sub Brand | Straight Blade Devices |
| Type | Plug |
| UNSPSC | 39121402 |
| UPC | 78358517995 |
| Vendor Name | HUBBELL WIRING DEVICE/KELLEMS |
| Vendor Number | 783585 |
| Vendor Short Name | HUBW |
| Voltage Rating | 125 V;125 Volt AC |
| Voltage Rating Description | 125 V |
| Wattage | 2,000 W |
| Wire Size | #18 AWG to #10 AWG |
