| Manufacturer Name | HUBBELL WIRING DEVICES/KELLEMS |
| MfgPartNo | PBS4 |
| Actuator | Push Buttons |
| Additional Information | Overall Dimension 1 Inch Inner Diameter x 1.125 Inch Outer Diameter; Temperature Rating -40 to 75 Deg C |
| Amperage Rating | 6 A |
| Application | Single Speed |
| Approval | CSA |
| Base Price | 0.0000 |
| Brand ID | WIRING DEVICE-KELLEMS |
| Brand Name | Hubbell Wiring Device-Kellems |
| Carton Quantity | 10 |
| Catalog Number | PBS4 |
| Color | Yellow |
| Commerce Sector | Construction Materials |
| Commodity Code | 42350 |
| Commodity Description | Pendant Station Complete Assemblies |
| Connection | Terminal Screws |
| Contact Configuration | Momentary |
| Contact Rating | Pilot Duty Only;6 Amp at 120 Volt AC, 3 Amp at 240 Volt, 0.55 Amp at 250 Volt, 1.1 Amp at 125 Volt DC |
| CountryOfOrigin | US |
| DDCATEGORY | 2165 |
| Description Long | Switches and Lighting Controls, Industrial Grade, Pendant Controls, PushButton Station, 4) Buttons- Single Speed, Pilot Duty, 250V AC Max, Terminal Screws, Yellow |
| Description Short | Switches and Lighting Controls, Industrial Grade, Pendant Controls, PushButton Station, 4) Buttons- Single Speed, Pilot Duty, 250V AC Max, Terminal Screws, Yellow |
| Directory | CIS |
| EU RoHS Indicator | No |
| Enclosure | NEMA 3R;NEMA 3R, IP44 |
| Environmental Conditions | Indoor and Outdoor |
| FEATURES Bullets | 4 button;Single speed |
| Families | 2165 |
| Family Description | Pendant Station Complete Assemblies |
| Finish | Yellow |
| Image Location | * Image |
| Indicator | None |
| Indicator S Type | None |
| Industry | ELX |
| Ingress Protection | IP44 |
| InvoiceDescription | BUTTON STATION, 4 BUTTON 1 SPEED;1 SPD PEND PB STN |
| Item Number | 61041 |
| Long Description | PUSH BUTTON PENDANT STATION, PUSHBUTTON 1-SPEED TYPE; VINYL RUBBER MATERIAL; 3.25 INCH WIDTH X 4.38 INCH DEPTH X 13.69 INCH HEIGHT SIZE; YELLOW FINISH; 6 AMP AT 120 VOLT AC, 3 AMP AT 240 VOLT, 0.55 AMP AT 250 VOLT, 1.1 AMP AT 125 VOLT DC CONTACT RATING |
| MSDS Form Number | * |
| Material | Non-Metallic;Vinyl Rubber |
| Material Mounting Hardware | Cable Mounted |
| Model | PBS |
| Mounting | Cable Mounted |
| Noun | * |
| Number Of Elements | 4 |
| Number Of Poles | 2 |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Operating Temperature | Maximum continuous 75C and minimum -40C without Impact |
| Operator Color | Black |
| Operator Type | Flush Round |
| Performance | Environmental - Operating Temperatures - Max Continuous- 75 C, Minimum -40 w/o Impact |
| Phase | 1 |
| Product Description | BUTTON STATION, 4 BUTTON 1 SPEED |
| Product Keywords | WEBREADY |
| Product Name | Industrial Grade, Pendant Controls, PushButton Station, 4) Buttons- Single Speed, Pilot Duty, 250V AC Max, Terminal Screws |
| ProductLine | HUBW |
| Series | Heavy Duty |
| Size | Full Sized;3.25 Inch Width x 4.38 Inch Depth x 13.69 Inch Height |
| Special Features | Standard Product |
| Standard | CSA Certified |
| Sub Brand | Magnetic Starter Controls |
| Type | Single Speed;Pushbutton 1-Speed |
| UNSPSC | 39121561 |
| UPC | 78358561041 |
| Vendor Name | HUBBELL WIRING DEVICE/KELLEMS |
| Vendor Number | 783585 |
| Vendor Short Name | HUBW |
| Voltage Rating | 250 V |
