| Manufacturer Name | HUBBELL WIRING DEVICES/KELLEMS |
| MfgPartNo | SEC75GA |
| Additional Information | Temperature Rating -30 to 100 Deg F |
| Application | Straight Male Connector;Hazardous Location |
| Approval | UL 514B, CSA |
| Base Price | 0.0000 |
| Catalog Number | SEC75GA |
| Color | Gray |
| Commerce Sector | Construction Materials |
| Commodity Code | 24900 |
| Commodity Description | Cable & Cord Grips |
| Conductor Range | 0.45-0.71 in (11.4-18.0 mm) |
| Cord Diameter | 0.45-0.71 in |
| Cord Size | 0.45 to 0.71 Inch |
| CountryOfOrigin | US |
| DDCATEGORY | 130 |
| Degree Of Protection IP | IP66 |
| Description Long | "Kellems Wire Management, Cord Connectors, European Style, .45-.71"", 3/4"", Gray" |
| Description Short | "Kellems Wire Management, Cord Connectors, European Style, .45-.71"", 3/4"", Gray" |
| Directory | CIS |
| EU RoHS Indicator | Yes |
| Environmental Conditions | Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting. |
| FEATURES Bullets | Connector body is a one-piece design with machined threads;Low profile |
| Families | 130 |
| Family Description | Cable & Cord Grips |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | "CORD CONN, EURO, .45""-.71"", 3/4"" NPT, GY";3/4NPT EURO CORD CONN |
| Item Number | 01814 |
| Long Description | CORD CONNECTOR, STRAIGHT MALE TYPE; GRAY NYLON MATERIAL; 1.42 INCH DIA X 2 INCH L SIZE; UL 514B, CSA APPROVAL; HAZARDOUS LOCATION APPLICATION; 3/4 INCH NPT THREAD SIZE; 0.45 TO 0.71 INCH CORD SIZE; TEMPERATURE RATING -30 TO 100 DEG F; SEC MODEL |
| MSDS Form Number | * |
| Material | Gray Nylon |
| Material Mounting Hardware | Locknut or Tapped Opening |
| Material Quality | Non-Metallic |
| Model | SEC |
| Mounting | Locknut or Tapped Opening |
| NEMA Rating | IP66 |
| Noun | * |
| Number Of Conductors | Single |
| Operating Temperature Maximum | 225 F |
| Operating Temperature Minimum | -22 F |
| Pallet Quantity | 10800 |
| Performance | Environmental - Flammability - UL 94V-2;Environmental - Operating Temperatures - -22F to 225F (-30C to 107C);Environmental - Protection Class - IP66 Suitability |
| Product Description | "CORD CONN, EURO, .45""-.71"", 3/4"" NPT, GY" |
| Product Keywords | WEBREADY |
| Product Name | "Kellems Wire Management, Cord Connectors, European Style, .45-.71"", 3/4"", Gray" |
| ProductLine | HUBW |
| Series | Low Profile NPT |
| Size | "3/4"" NPT" IN;1.42 Inch Dia x 2 Inch L |
| Special Features | Standard Product |
| Standard | UL Listed |
| Standards RoHS Compliance Status | CM |
| Thread Size | 3/4 Inch NPT |
| Type | Connector;Straight Male |
| UNSPSC | 39121431 |
| UPC | 78358501814 |
| Vendor Name | HUBBELL WIRING DEVICE/KELLEMS |
| Vendor Number | 783585 |
| Vendor Short Name | HUBW |
