| Manufacturer Name | IDEAL INDUSTRIES INC |
| MfgPartNo | 89-049 |
| Additional Information | BandWidth 3 GHz; Dielectric Diameter 0.134 to 14 Inch |
| Application | For CCTV System Installations/Integrations And General Purpose Applications on RG 59 Plenum Cable;CCTV, Broadband |
| Base Price | 0.0000 |
| Body Material | Nickel Plated Brass |
| Brand Name | Ideal;INSITE[TM] |
| Cable Insulation Outer Diameter | 0.193 to 0224 Inch |
| Cable Type | RG59, Plenum |
| Catalog Number | 89-049 |
| Center Conductor Size | 18 to 23 AWG Solid |
| Commerce Sector | Construction Materials |
| Commodity Code | 51300 |
| Commodity Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| Conductor Range | 029 - 042 IN, 20 - 18 AWG Solid Center Conductor |
| Configuration | Straight |
| Contact Material | Gold Plated |
| CountryOfOrigin | CHN |
| Coupling Style | BNC |
| DDCATEGORY | 574 |
| Directory | CIS |
| Families | 574 |
| Family Description | Plugs,Conn,Inlets,Outlets,Lampholdr |
| Finish | Nickel |
| Image Location | * Image |
| Impedance | 75 Ohm |
| Industry | ELX |
| InvoiceDescription | RG59 PLENM INSITE BNC CON 15CD;RG59 COMPR CONN |
| Item Number | 89049 |
| Long Description | COMPRESSION CONNECTOR, RG59, PLENUM CABLE TYPE; STRAIGHT CONFIGURATION; CCTV, BROADBAND APPLICATION; 15 PER CARD STANDARD PACKAGE; NICKEL PLATED BRASS BODY MATERIAL; 0.193 TO 0224 INCH CABLE INSULATION OUTER DIAMETER; GOLD PLATED CONTACT MATERIAL |
| MSDS Form Number | * |
| Material | Brass |
| Noun | * |
| Product Description | RG59 COMPR CONN |
| Product Keywords | WEBREADY |
| Product Name | Wire or cable compression connector |
| ProductLine | IDEAL |
| Special Features | Features: Designed For CCTV System Installations/Integrations And General Purpose Applications; RG-6 And RG-59 Versions. 2 Connectors To Cover Most Plenum Rated Coax Cables Available In The Market; Compression Sleeve Adapts To A Wide Range Of Outer Jacket Cable Diameters; Solid All-Brass Construction For Permanent Installations; Gold Plated Contact Pin And Mating Area; Color Bands For Cable Series Identification; Nickel-Plated, Brass-Construction For Superior Corrosion Resistance; Moisture-Inhibiting Design; Use 30-793 Compression Tool; 75 OHM Nominal Impedance; Nominal Impedance: 75 OHM; Dielectric Diameter: 0.130 - 0.141 IN; Coaxial Cable Type: RG-59 Plenum; Overall Jacket Diameter: 0.188 - 0.230 IN |
| Standard Package | 15 per Card |
| Type | BNC |
| UNSPSC | 39121448 |
| UPC | 78325089049 |
| Vendor Name | IDEAL INDUSTRIES INC |
| Vendor Number | 783250 |
| Vendor Short Name | IDEAL |
