| Manufacturer Name | INTERMATIC INC |
| MfgPartNo | FF60MC |
| Action | 1 x SPST |
| Additional Information | RoHS Compliant; Voltage Rating 125 to 277 Volt AC 60 Hertz |
| Amperage Rating | 15 A |
| Application | Indoor, CFLs Lighting, Fans, Electric Motors, Heaters, HVACR;Fan, Lighting, Motor, Heater |
| Approval | UL, CSA (Canada and US) |
| Base Price | 0.0000 |
| Brand Name | Intermatic |
| Catalog Number | FF60MC |
| Color | Brushed Metal Plate, White Knob |
| Commerce Sector | Construction Materials |
| Commodity Code | 44100 |
| Commodity Description | Electromechanical Time Switches |
| Connection | Teeter Type |
| Contact Configuration | 1 NO |
| Contact Current Rating | 20 Amp at 125 Volt AC 50/60 Hertz (Resistive), 10 Amp at 250/277 Volt AC 50/60 Hertz (Resistive), 7 Amp at 125 Volt AC (Tungsten) |
| Contact Power Rating | 1 HP at 125 Volt AC 50/60 Hertz, 2 HP at 250 Volt AC 50/60 Hertz |
| Contact Rating | 7 AMP @ 125 VAC (Tungsten), 20 AMP @ 125 VAC (Resistive), 10 AMP @ 250/277 VAC (Resistive) |
| CountryOfOrigin | TN |
| DDCATEGORY | 2172 |
| Directory | CIS |
| Families | 2172 |
| Family Description | Electromechanical Time Switches |
| Frequency Rating | 50/60 HZ |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | Spring Wound Countdown Timer, Commercial, 125-277 VAC, 50/60 Hz, SPST, 60 Minute Max, Without Hold, Silver;60MIN SPR WOUND TMR |
| Item Number | 00560 |
| Long Description | TIMER, COMMERCIAL TYPE; 1.75 INCH WIDTH X 1.25 INCH DEPTH X 4.125 INCH HEIGHT SIZE; BRUSHED METAL PLATE, WHITE KNOB COLOR; WITHOUT HOLD OPERATION TYPE; UL, CSA (CANADA AND US) APPROVAL; FAN, LIGHTING, MOTOR, HEATER APPLICATION; WALL MOUNT MOUNTING |
| MSDS Form Number | * |
| Model | FF |
| Motor Power | 1 HP @ 120 VAC, 2 HP @ 240 VAC |
| Mounting | Wall Mount |
| Noun | * |
| Number Of Poles | 1 |
| Operating Temperature | 32 to 104 Deg F |
| Operation Type | Without Hold |
| Product Description | 60MIN SPR WOUND TMR |
| Product Keywords | WEBREADY |
| Product Name | Time switch |
| ProductLine | INT-MAT |
| Size | 2.79 HEIGHT X 1.6 WIDTH X 1.19 DEPTH IN, 70.86 HEIGHT X 40.64 WIDTH X 30.22 DEPTH MM;1.75 Inch Width x 1.25 Inch Depth x 4.125 Inch Height |
| Special Features | "Features: Energy-Efficient Mechanical Timers do not require Electricity to Operate, Automatically Limit the ON Times, Rugged Time Dial Plate Easily withstands the Abuse Encountered in Commercial Environments, Commercial ""Brushed Metal"" (Plastic Construction) look meets NEC Requirements, Press-On Knob Design Ensures Quick and Easy Installation, CFL Compatible, Provide Direct Replacement of a Standard Wall Switch in a Single Gang 2-1/2 IN Deep Junction Boxes, Spiral Time Scale to Provide Easy Selection of the Time Setting, Standard Industry Accepted Molded Plate and Knob, Secure Teeter-Type Terminal, 1 Year Warranty" |
| Standard | cCSAus Certified, UL Listed, UL Recognized, HVACR, NEC |
| Switch Type | SPST |
| Time Cycle | 60 Minute |
| Timer Duration | 60 MIN |
| Timing Range | 0-60 min |
| Type | Commercial Spring Wound Auto-Off;Commercial |
| UNSPSC | 39122208 |
| UPC | 07827500560 |
| Vendor Name | INTERMATIC, INC |
| Vendor Number | 078275 |
| Vendor Short Name | INT-MAT |
| Voltage Rating | 125 to 277 VAC |
