| Manufacturer Name | INTERMATIC INC |
| MfgPartNo | T101 |
| Action | SPST |
| Additional Information | Includes On/Off Tripper; Power Consumption 3 Watt; Wire Size 14 to 8 AWG; Knockout Size (1) 1/2 Inch and (1) 3/4 Inch (Side/Back), (2) 1/2 Inch and (2) 3/4 Inch (Back) |
| Amperage Rating | 40 A |
| Application | Commercial, Industrial, Residential, Outdoor, HVACR;Indoor, Post Lantern, Sign, Pool Heater, Filter, Hydro chlorinator, Air Conditioning, Blower, Electric Fence, Pump, Heating/Ventilating System, Music and Signal System, Fan, Poultry Fogger, Conveyer |
| Approval | UL (Canada and US), CSA (Canada and US) |
| Base Price | 0.0000 |
| Brand Name | Intermatic |
| Catalog Number | T101 |
| Commerce Sector | Construction Materials |
| Commodity Code | 44100 |
| Commodity Description | Electromechanical Time Switches |
| Connection | Teeter Type |
| Contact Configuration | 1 NO |
| Contact Rating | 40 AMP @ 120 - 480 VAC (Resistive), 40 AMP @ 120 - 277 (Tungsten) |
| CountryOfOrigin | MX |
| Current Rating | 40 Amp at 120 to 480 Volt AC (Resistive), 40 Amp at 120 to 277 Volt AC (Tungsten/Inductive) |
| DDCATEGORY | 2172 |
| Directory | CIS |
| Enclosure | NEMA 1 |
| Families | 2172 |
| Family Description | Electromechanical Time Switches |
| Finish | Gray |
| Frequency Rating | 60 HZ |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | 24-Hour Mechanical Time Switch, 120 VAC, 60Hz, SPST, Indoor Metal Enclosure, 1 Hour Interval;SPST 40A 125V TIME SW |
| Item Number | 00001 |
| Long Description | ELECTROMECHANICAL TIME SWITCH, 24 HOUR TYPE; STEEL MATERIAL; 5 INCH WIDTH X 3 INCH DEPTH X 7-3/4 INCH HEIGHT SIZE; GRAY FINISH; 1 TO 12 PER DAY MAX. NUMBER OF OPERATIONS; 1 HOUR MIN. OFF TIME; 1 HOUR MIN. ON TIME |
| MSDS Form Number | * |
| Material | Steel |
| Maximum Number Of Operations | 1 to 12 per Day |
| Minimum OFF Time | 1 Hour |
| Minimum ON Time | 1 Hour |
| Model | T100 |
| Motor Power | 2 HP @ 120 VAC, 5 HP @ 240 VAC |
| Mounting | Wall Mount;Enclosure |
| Noun | * |
| Number Of Poles | 1 |
| Operating Temperature | -40 to +130 DEG F, -40 to +54 DEG C;-40 to 130 Deg F |
| Pilot Duty | 1000 VA @ 120 - 277 VAC |
| Power Rating | 2 HP at 120 Volt AC (24 FLA) |
| Product Description | SPST 40A 125V TIME SW |
| Product Keywords | WEBREADY |
| Product Name | Time switch |
| ProductLine | INT-MAT |
| Reserve Power | No |
| Size | 5 LENGTH X 3 WIDTH X 7-3/4 HEIGHT IN, 12.70 LENGTH X 7.62 WIDTH X 19.69 HEIGHT CM;5 Inch Width x 3 Inch Depth x 7-3/4 Inch Height |
| Special Features | Features: Provides direct 24-Hour control of most loads, 1 to 12 ON/OFF operations each day, Minimum ON/OFF times of 1 hour, Manual override, 1 Year Warranty |
| Standard | cCSAus Certified, HVACR |
| Switch Type | SPST |
| Timer Duration | 24 HR |
| Timing Range | 0-24 h |
| Type | Electromechanical;24 Hour |
| UNSPSC | 39122208 |
| UPC | 07827500001 |
| Vendor Name | INTERMATIC, INC |
| Vendor Number | 078275 |
| Vendor Short Name | INT-MAT |
| Voltage Rating | 125 VAC;125 Volt AC at 60 Hertz |
| Wattage | 3 W |
