LEV 7545-C

EB PLUG LOCK NON-GRND 2PO 2WI 15A125V

Page Loading...
LEVITON MFG CO.
EB PLUG LOCK NON-GRND 2PO 2WI 15A125V

Mouse over image to zoom, click to enlarge

Description:
EB PLUG LOCK NON-GRND 2PO 2WI 15A125V

UPC:  07847751565

Part Number: 7545-C

UNSPSC: 39121402

Status:  UNKNOWN

Retail Price:  $41.22 / EA
Your Price:  $22.54 / EA


Quantity  EA

Specifications

Manufacturer Name LEVITON MFG CO.
MfgPartNo 7545-C
Additional Information Temperature Rating -40 to 60 Deg C; Wire Size 18 to 10 AWG; Application Industrial
Amperage Rating 15 A
Application Industrial
Approval UL, CSA C22.2, NOM 057
Base Price 0.0000
Brand Name Leviton;Black & White[R]
Catalog Number 7545-C
Color Black/White;Black, White
Commerce Sector Construction Materials
Commodity Code 51300
Commodity Description Plugs,Conn,Inlets,Outlets,Lampholdr
Configuration L1-15P
Constructional Feature Abrasion Resistant, Chemical Resistant, Impact Resistant
Cord Size 0.24 to 0.7 Inch
CountryOfOrigin US
Current Rating 15 Ampere
DDCATEGORY 574
Directory CIS
Environmental Conditions Flammability (Rated V-2 per UL94);Operating Temperature Range (-40 to +60 DEG C)
Families 574
Family Description Plugs,Conn,Inlets,Outlets,Lampholdr
Ground Type Non-Grounding
Image Location * Image
Industry ELX
InvoiceDescription EB PLUG LOCK NON-GRND 2PO 2WI 15A125V;LKG PLUG-NEMA L1-15P
Item Number 51565
Long Description LOCKING PLUG, NON-POLARIZED TYPE; SUPER TOUGH NYLON (BODY), SOLID BRASS (BLADE/CONTACT) MATERIAL; BLACK, WHITE COLOR; L1-15P CONFIGURATION; 2 WIRE(S); UL, CSA C22.2, NOM 057 APPROVAL; 125 V VOLTAGE RATING; 15 AMPERE CURRENT RATING; NON-GROUNDING
MSDS Form Number *
Material Super Tough Nylon (Body), Solid Brass (Blade/Contact)
NEMA Rating L1-15P
Noun *
Number Of Poles 2
Number Of Wires 2
Product Description EB PLUG LOCK NON-GRND 2PO 2WI 15A125V
Product Keywords WEBREADY
Product Name Electrical plugs
ProductLine LEV
Size 1.53 Dia x 2.61 H IN
Standard NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 42 (File LR-406);UL Fed Spec WC-596 (File E13393);UL Listed 498 (File E13393)
Sub Brand Black & White
Type Locking Plug;Non-Polarized
UNSPSC 39121402
UPC 07847751565
Vendor Name LEVITON MFG CO.
Vendor Number 078477
Vendor Short Name LEV
Voltage Rating 125 V
Wire Size 18-10 AWG (Terminal Accommodation);.230-.650 IN (Cord Grip Range)
