LEV IP710-DLZ

W/I/LA SLIDE DIM 0-10V SP-3W 1200VA120V

Page Loading...
LEVITON MFG CO.
W/I/LA SLIDE DIM 0-10V SP-3W 1200VA120V

Mouse over image to zoom, click to enlarge

Description:
W/I/LA SLIDE DIM 0-10V SP-3W 1200VA120V

UPC:  07847728238

Part Number: IP710-DLZ

UNSPSC: 39122206

Status:  UNKNOWN

Call for price



Specifications

Manufacturer Name LEVITON MFG CO.
MfgPartNo IP710-DLZ
Additional Information Temperature Rating 0 to 55 Deg C
Application Commercial;Commercial, Residential
Approval UL, CSA
Base Price 0.0000
Brand Name IllumaTech[R], Decora[R]
Catalog Number IP710-DLZ
Commerce Sector Construction Materials
Commodity Code 74210
Commodity Description Lighting Dimmers
CountryOfOrigin CN
DDCATEGORY 2224
Depth 1.41 in
Directory CIS
Environmental Conditions Flammability (Rated V-2 per UL94)
Families 2224
Family Description Dimmer Switches & Systems
Finish White, Ivory, Light Almond
Frequency Rating Maximum 60 Hz
Height 4.15 in
Image Location * Image
Industry ELX
InvoiceDescription W/I/LA SLIDE DIM 0-10V SP-3W 1200VA120V;ILLUMATECH MARK 7 DMR
Item Number 28238
Load 1200
Load Rating 1200/1500 VA
Load Type Fluorescent
Long Description DIMMER, SLIDE, WALL DIMMER TYPE; 2.12 INCH W X 1.41 INCH D X 4.15 INCH H SIZE; WHITE, IVORY, LIGHT ALMOND FINISH; 1-POLE, 3-WAY, MULTI-LOCATION OPERATION TYPE; UL, CSA APPROVAL; COMMERCIAL, RESIDENTIAL APPLICATION; 120/277 VAC AT 60 HZ VOLTAGE RATING
MSDS Form Number *
Model Series IP710
Mounting Type Wall
Noun *
Number Of Poles 1
Operating Temperature Maximum 130 +
Operating Temperature Minimum 32 F
Operation Type 1-Pole, 3-Way, Multi-Location
Operator Type Slide, Electro Mechanical Preset On/Off Switch
Product Description W/I/LA SLIDE DIM 0-10V SP-3W 1200VA120V
Product Keywords WEBREADY
Product Name Dimmer switch
ProductLine LEV
Size 2.12 Inch W x 1.41 Inch D x 4.15 Inch H
Special Features 5 Years Limited Warranty, Made in China
Standard UL Listed (E-31373), CSA Certified (LR-3413)
Type Electro-Mechanical;Slide, Wall Dimmer
UNSPSC 39122206
UPC 07847728238
Vendor Name LEVITON MFG CO.
Vendor Number 078477
Vendor Short Name LEV
Voltage Rating 120;277;120/277 VAC at 60 Hz
Wall Plate Type Decora Plus Screwless, Standard Designer (Not Included)
Wattage 1200
Width 2.12 in

Resources

CatalogNumber IP710-DLZ
Full Image
Manufacturer Specification Sheet
MfrProductUrl

Package Information

SellPkgQty 1
