LEV ODS06-IDW

WH PIR OC SENS WL SW 180D 1600SF120/277V

Page Loading...
LEVITON MFG CO.
WH PIR OC SENS WL SW 180D 1600SF120/277V

Mouse over image to zoom, click to enlarge

Description:
WH PIR OC SENS WL SW 180D 1600SF120/277V

UPC:  07847770527

Part Number: ODS06-IDW

UNSPSC: 45111808

Status:  UNKNOWN

Your Price:  $56.23 / EA


Quantity  EA

Specifications

Manufacturer Name LEVITON MFG CO.
MfgPartNo ODS06-IDW
Additional Information RoHS Compliant; Relative Humidity 20 to 90 Percent Non-Condensing; Operating Temperature 32 to 122 Degree F; Applicable Standard ISO 9001, ASHRAE 90.1, FCC, NOM, CEC, Title 24 Compliant
Application Commercial Grade, Small Office, Lounge, Conference Room, Classroom
Approval UL (Canada and US)
Area Coverage 1600 Square Foot
Base Price 0.0000
Brand Name Decora[R]
Catalog Number ODS06-IDW
Commerce Sector Construction Materials
Commodity Code 74310
Commodity Description Lighting Occupancy Sensors
CountryOfOrigin CN
DDCATEGORY 0
Directory CIS
Families 0
Family Description UnCategorized
Field Of View 180 Degree
Finish White
Image Location * Image
Industry ELX
InvoiceDescription WH PIR OC SENS WL SW 180D 1600SF120/277V;SENSOR WALL SWITCH
Item Number 70527
Load Rating 600 Watt at 120 Volt AC (Incandescent), 800 Volt Amp at 120 Volt AC and 1500 Volt Amp at 277 Volt (Fluorescent), 1/4 HP at 120 Volt (Motor)
Load Type Incandescent, Fluorescent, Motor
Long Description OCCUPANCY SENSOR WALL SWITCH, SENSOR WITH 1-RELAY TYPE; 1.75 INCH WIDTH X 1.83 INCH DEPTH X 4.06 INCH HEIGHT SIZE; WHITE FINISH; UL (CANADA AND US) APPROVAL; COMMERCIAL GRADE, SMALL OFFICE, LOUNGE, CONFERENCE ROOM, CLASSROOM APPLICATION
MSDS Form Number *
Mounting Wall;Wall Mount
Noun *
Product Description WH PIR OC SENS WL SW 180D 1600SF120/277V
Product Keywords WEBREADY
Product Name Lighting controls
ProductLine LEV
Sensor Type Passive Infrared
Size 1.75 Inch Width x 1.83 Inch Depth x 4.06 Inch Height
Special Features 180-Degree Field of View
Standard UL Listed
Supply Voltage 120/277 VAC
Time Delay 30 Second to 30 Minute
Type Occupancy Sensor;Sensor with 1-Relay
UNSPSC 45111808
UPC 07847770527
Vendor Name LEVITON MFG CO.
Vendor Number 078477
Vendor Short Name LEV
Voltage Rating 120 to 277 Volt AC 50/60 Hertz

Resources

CatalogNumber ODS06-IDW
Full Image
Manufacturer Specification Sheet
MfrProductUrl

Package Information

SellPkgQty 1

Time Zone
