| Manufacturer Name | LEVITON MFG CO. |
| MfgPartNo | OSSMT-GDW |
| Additional Information | Operating Temperature Rating 32 to 104 Deg F; Relative Humidity 20 to 90 Percent Non-Condensing; Switching Type 1-Pole; Applicable Standard Title 24, USMCA |
| Application | Commercial;Private and Executive Office, Conference Room, Classroom, Storage Area, Lounge, Training Area, Retrofit, Multi-Location Switching |
| Approval | ETL, CSA, CEC, CETL, FCC, NOM |
| Area Coverage | 2400 Square Foot |
| Base Price | 0.0000 |
| Brand Name | Leviton;Decora[R] |
| Catalog Number | OSSMT-GDW |
| Commerce Sector | Construction Materials |
| Commodity Code | 74310 |
| Commodity Description | Lighting Occupancy Sensors |
| CountryOfOrigin | CN |
| DDCATEGORY | 578 |
| Directory | CIS |
| Environmental Conditions | Operating Temperature (0 to +40 DEG C);Storage Temperature (-10 to +85 DEG C);Humidity (20% to 90% Non-Condensing) |
| Families | 578 |
| Family Description | Motion Sensing Devices |
| Field Of View | 180 Degree |
| Finish | White |
| Frequency Rating | 50/60 Hz |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | MT WB OCC, 120-277VAC, NO NEUTRAL WHITE;MULTI-TECH OS SENSOR |
| Item Number | 40696 |
| Load Rating | 800 Watt at 120 Volt (Incandescent), 1200 Volt Amp at 120 Volt/2700 Volt Amp at 277 Volt/1500 Volt Amp at 347 Volt (Fluorescent), 1/4 HP at 120 Volt (Motor) |
| Load Type | Incandescent/Fluorescent/Motor |
| Long Description | OCCUPANCY SENSOR, SELF-ADAPTIVE, NO NEUTRAL TYPE; 1.75 INCH WIDTH X 1.85 INCH DEPTH X 4.06 INCH HEIGHT SIZE; WHITE FINISH; ETL, CSA, CEC, CETL, FCC, NOM APPROVAL |
| MSDS Form Number | * |
| Model | OSSMT |
| Mounting | Wall |
| Noun | * |
| Power Consumption | 110 @ 120V (U/S & PIR);70 @ 120V (PIR only);340 @ 277V (U/S & PIR);310 @ 277V (PIR only) |
| Product Description | MT WB OCC, 120-277VAC, NO NEUTRAL WHITE |
| Product Keywords | WEBREADY |
| Product Name | Lighting controls |
| ProductLine | LEV |
| Sensor Type | Multi-Technology, Passive Infrared/Ultrasonic |
| Size | 46 H x 1.75 W x 1.85 D IN;1.75 Inch Width x 1.85 Inch Depth x 4.06 Inch Height |
| Special Features | Fast, Simple Installation Fits in a Standard Wall Box and Replaces a Single-Pole Wall-Switch, Neutral and No Neutral Options Available, Convenient Pushbutton Provides Manual-ON/OFF Light Switching at any Time, Segmented Fresnel Lens Provides Optimum Sensi |
| Standard | ETL\cETL Listed;CSA Certified;CEC Title 24 Compliant;FCC Compliant;NAFTA (CF434);UL Listed;cUL |
| Sub Brand | Decora |
| Supply Voltage | 120/230/277/347 VAC |
| Time Delay | 30 Second to 30 Minute |
| Type | Occupancy Sensor;Single-Pole Switch;Self-Adaptive, No Neutral |
| UNSPSC | 45111808 |
| UPC | 07847740696 |
| Vendor Name | LEVITON MFG CO. |
| Vendor Number | 078477 |
| Vendor Short Name | LEV |
| Voltage Rating | 120 to 277 Volt AC 50/60 Hertz |
