| Manufacturer Name | MERSEN USA Newburyport-MA, LLC |
| MfgPartNo | 30311R |
| AC Voltage Rating | 600 V |
| Additional Information | RoHS Compliant; Mounting Type DIN Rail/Screw; Short Circuit Current Rating 200 Kiloamp; Overall Dimension 3.04 Inch Length x 0.750 Inch Width x 1.31 Inch Height; Torque Rating 20 Inch-Pound |
| Amperage Rating | 30 A |
| Approval | UL 4248, CSA |
| Base Price | 0.0000 |
| Body Material | Glass Filled Polycarbonate |
| Catalog Number | 30311R |
| Class | Class CC |
| Clip Type | Tin Plated Copper Alloy |
| Commerce Sector | Construction Materials |
| Commodity Code | 61310 |
| Commodity Description | Fuseholders & Fuseblocks |
| Connection | Screw with Reinforced Clip |
| DC Voltage Rating | 600 V |
| DDCATEGORY | 585 |
| Directory | CIS |
| Families | 585 |
| Family Description | Fuseholders & Fuseblocks |
| Fuse Current Rating | 30 Amp |
| Fuse Type | Class CC |
| Fuse Voltage Rating | 600 Volt AC/DC |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | Fuse Block 600VAC 600VDC Class CC 30A 1-Pole Screw with Reinforced Clip;30A 600V SP FUSE BLK |
| Item Number | 75839 |
| Long Description | FUSE BLOCK, OPEN STYLE TYPE; 14 TO 10 AWG (COPPER) WIRE SIZE; UL 4248, CSA APPROVAL; GLASS FILLED POLYCARBONATE BODY MATERIAL; 1 POLE(S); SCREW WITH DOUBLE QUICK-CONNECT TERMINAL TYPE; CLASS CC FUSE TYPE; 30 AMP FUSE CURRENT RATING |
| MSDS Form Number | * |
| Material | Glass Filled Polycarbonate |
| Maximum Operating Temperature | 80 C |
| Model | 303 |
| Mounting | Screw Mount or DIN Rail |
| Noun | * |
| Number Of Poles | 1 |
| Phase | 1 |
| Product Description | 30A 600V SP FUSE BLK |
| Product Keywords | WEBREADY |
| Product Name | Fuse holder |
| ProductLine | MFP |
| Size | 3.04 x 0.75 x 1.31 in |
| Standard | UL listed, guide IZLT, File E52283 CSA certified class 6225, File 32169 |
| Terminal Type | Screw with Double Quick-Connect |
| Type | UL/CSA Fuse Bases;Open Style |
| UNSPSC | 39121624 |
| UPC | 78200175839 |
| Vendor Name | MERSEN (FORMERLY FERRAZ SHAWMUT INC) |
| Vendor Number | 782001 |
| Vendor Short Name | MFZ |
| Voltage Rating | 600 VAC |
| Wire Size | 14 to 10 AWG (Copper) |
