| Manufacturer Name | MERSEN USA Newburyport-MA, LLC |
| MfgPartNo | A100P40-4 |
| AC Voltage Rating | 1000 V |
| Additional Information | APPLICATION AC OR DC DRIVE, REDUCED VOLTAGE MOTOR STARTER AND UPS SYSTEM; CONTROLLED ARC VOLTAGE; CURRENT LIMITING |
| Amperage Rating | 40 A |
| Application | Protection of UPS systems AC/DC drives, reduced voltage motor starters and other 1000V or less semiconductor devices |
| Approval | UL |
| Base Price | 0.0000 |
| Brand Name | AMP-TRAP. |
| Case | GMG |
| Catalog Number | A100P40-4 |
| Characteristics | FAST ACTING |
| Commerce Sector | Construction Materials |
| Commodity Code | 61140 |
| Commodity Description | Semicond,Rectifier,Hi-Voltage Fuses |
| Connection | Blade |
| CountryOfOrigin | MX |
| Current Rating | 40 AMPERE |
| DDCATEGORY | 583 |
| Diameter | 1 INCH |
| Directory | CIS |
| Families | 583 |
| Family Description | Semicond,Rectifier,Hi-Voltage Fuses |
| Image Location | * Image |
| Industry | ELX |
| Interrupting Rating | 100 KILOAMPERE |
| InvoiceDescription | High Speed Fuse Amp-Trap A100P 1000VAC 750VDC 40A Bolted Blade;1000V SEMICOND FUSE |
| Item Number | 94963 |
| Length | 5 INCH |
| Long Description | SEMICONDUCTOR PROTECTION FUSE, ROUND, SEMICONDUCTOR TYPE; 5 INCH; UL APPROVAL; 1000 VAC/750 VDC VOLTAGE RATING; 1 INCH DIAMETER; 100 KILOAMPERE INTERRUPTING RATING; 40 AMPERE CURRENT RATING; BLADE TERMINAL TYPE; FAST ACTING CHARACTERISTICS |
| MSDS Form Number | * |
| Model | A100P |
| Mounting | Bolted |
| Noun | * |
| Product Description | 1000V SEMICOND FUSE |
| Product Keywords | WEBREADY |
| Product Name | Semiconductor fuse |
| ProductLine | MFP |
| Size | 5 x 1 in |
| Special Features | Low I2t minimizes damage to protected components on short circuit Controlled arc voltage reduces stress to circuit components during fuse clearing Wide range of ampere ratings |
| Standard | UL recognized component File E60314 AC: UL guide no. JFHR2 (35-600A) DC: self-certified |
| Terminal Type | BLADE |
| Type | Round Body High-Speed Fuse-Links AC Protection;ROUND, SEMICONDUCTOR |
| UNSPSC | 39121628 |
| UPC | 78200194963 |
| Vendor Name | MERSEN (FORMERLY FERRAZ SHAWMUT INC) |
| Vendor Number | 782001 |
| Vendor Short Name | MFZ |
| Voltage Rating | 1000 V;1000 VAC/750 VDC |
