| Manufacturer Name | MERSEN USA Newburyport-MA, LLC |
| MfgPartNo | A155C2D0R0-125E |
| AC Voltage Rating | 15500 V |
| Additional Information | CURRENT LIMITING; HEIGHT 7.94 INCH; WIDTH 3 INCH |
| Amperage Rating | 125 A |
| Application | Protection for 5.5kV to 15.5kV transformers or distribution systems |
| Approval | UL |
| Base Price | 0.0000 |
| Body Material | PolyTube |
| Brand Name | AMP-TRAP. |
| Catalog Number | A155C2D0R0-125E |
| Commerce Sector | Construction Materials |
| Commodity Code | 61130 |
| Commodity Description | Current Limiting Fuses |
| Connection | Blade |
| Connection Material | Silver-Plated Copper |
| Current Rating | 125E AMPERE |
| DDCATEGORY | 582 |
| Directory | CIS |
| Families | 582 |
| Family Description | Current Limiting Fuses |
| Image Location | * Image |
| Indication Type | BLOWN FUSE |
| Industry | ELX |
| Interrupt Rating | 50 kA |
| Interrupting Rating | 50000 AMPERE (SYMMETRICAL) |
| InvoiceDescription | MV E-Rated Fuse 15500VAC 125A Clip-lock Series: D0R0 2 Barrels Visual Indicator;15.5KV E FUSE |
| Item Number | 80451 |
| Length | 22.81 INCH |
| Long Description | TRANSMISSION AND DISTRIBUTION FUSE, INDOOR DISTRIBUTION, TRANSFORMER TYPE; 22.81 INCH; UL APPROVAL; 15.5 KV VOLTAGE RATING; 50000 AMPERE (SYMMETRICAL) INTERRUPTING RATING; 125E AMPERE CURRENT RATING; CLIP LOCK TERMINAL TYPE; BLOWN FUSE INDICATION TYPE |
| MSDS Form Number | * |
| Model | CL-14 |
| Mounting | Clip-lock |
| Noun | * |
| Product Description | 15.5KV E FUSE |
| Product Keywords | WEBREADY |
| Product Name | Medium voltage fuse |
| ProductLine | MFP |
| Size | 22.81 x 3 x 7.94 in |
| Special Features | UL listed for compatibility with UL listed equipment Clip-lock mounting for reliable high integrity connection into circuit Current-limiting for superior equipment protection Non-venting for silent operation Metal embossed catalog number and manufacturing date for lasting identification Blown-fuse indicator to give positive identification of open fuse 2 lb tripped force - 0.50 Inch |
| Standard | Some UL Listed to standard File E143362 |
| Terminal Type | CLIP LOCK |
| Type | General Purpose Clip-Lock Fuses for Transformer Protection;INDOOR DISTRIBUTION, TRANSFORMER |
| Type Of Indicators | Visual Indicator |
| UNSPSC | 39121626 |
| UPC | 78200180451 |
| Vendor Name | MERSEN (FORMERLY FERRAZ SHAWMUT INC) |
| Vendor Number | 782001 |
| Vendor Short Name | MFZ |
| Voltage Rating | 15500 VAC;15.5 KV |
