| Manufacturer Name | MERSEN USA Newburyport-MA, LLC |
| MfgPartNo | A4J40 |
| AC Voltage Rating | 600 V |
| Additional Information | RoHS Compliant; Mounting Type Clip; Material Fiberglass (Body), Tin Plated Copper (Terminal); Application Capacitor, Load Center, Panel Board, Switch Board, Bus Duct, Feeder Circuit, Circuit Breaker, Lightning, Heating and General Load; Applicable Standar |
| Amperage Rating | 40 A |
| Application | Capacitors Load centers Panelboards Switchboards Bus duct Feeder circuits Circuit breakers Lighting, heating, and general loads |
| Approval | UL 248/248-8, CSA C22.2 |
| Base Price | 0.0000 |
| Body Material | PolyTube |
| Brand Name | Amp-Trap[R] |
| Catalog Number | A4J40 |
| Characteristics | Fast Acting |
| Class | Class J |
| Commerce Sector | Construction Materials |
| Commodity Code | 61130 |
| Commodity Description | Current Limiting Fuses |
| Connection | Ferrule |
| Connection Material | Tin-Plated Copper |
| CountryOfOrigin | MX |
| Current Rating | 40 Amp |
| DC Voltage Rating | 300 V |
| DDCATEGORY | 582 |
| Diameter | 1-1/16 Inch |
| Directory | CIS |
| Families | 582 |
| Family Description | Current Limiting Fuses |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 200 kA |
| Interrupting Rating | 200 Kiloamp (AC), 100 Kiloamp (DC) |
| InvoiceDescription | Fuse A4J - Class J - Fast-Acting 600VAC 300VDC 40A Ferrule;600V CLASS J FUSE |
| Item Number | 96022 |
| Length | 2-3/8 Inch |
| Long Description | POWER FUSE, CLASS J TYPE; 2-3/8 INCH; UL 248/248-8, CSA C22.2 APPROVAL; 600 VOLT AC, 300 VOLT DC VOLTAGE RATING; 1-1/16 INCH DIAMETER; 200 KILOAMP (AC), 100 KILOAMP (DC) INTERRUPTING RATING; 40 AMP CURRENT RATING; FERRULE TERMINAL TYPE |
| MSDS Form Number | * |
| Model | A4J |
| Mounting | Clip |
| Noun | * |
| Product Description | 600V CLASS J FUSE |
| Product Keywords | WEBREADY |
| Product Name | Cartridge fuses |
| ProductLine | MFP |
| Size | 2.38 x 1.06 in |
| Special Features | High current limitation for low peak let-thru current Unique dimensions prevent replacement by other fuse classes Fiberglass body provides dimensional stability in harsh industrial environments Easy-to-read imprint label for quick recognition and replacement |
| Standard | UL listed to standard 248-8 File E2137 CSA certified to standard C22.2 no. 248.8 DC listed to UL 248 IEC 269-2-1 |
| Terminal Type | Ferrule |
| Type | Class J |
| UNSPSC | 39121606 |
| UPC | 78200196022 |
| Vendor Name | MERSEN (FORMERLY FERRAZ SHAWMUT INC) |
| Vendor Number | 782001 |
| Vendor Short Name | MFZ |
| Voltage Rating | 600 VAC;600 Volt AC, 300 Volt DC |
Product Detail
