| Manufacturer Name | MERSEN USA Newburyport-MA, LLC |
| MfgPartNo | A70Q250-4 |
| Additional Information | APPLICATION INVERTER; CURRENT LIMITING |
| Amperage Rating | 250 A |
| Application | Protection of inverters and other equipment requiring the best AC or DC protection in this voltage range |
| Approval | UL 198L |
| Base Price | 0.0000 |
| Brand Name | Ferraz Shawmut;AMP-TRAP. |
| Catalog Number | A70Q250-4 |
| Characteristics | EXTREMELY FAST ACTING |
| Commerce Sector | Construction Materials |
| Commodity Code | 61140 |
| Commodity Description | Semicond,Rectifier,Hi-Voltage Fuses |
| Connection | Bolted |
| CountryOfOrigin | MX |
| Current Rating | 250 AMPERE |
| DDCATEGORY | 583 |
| Diameter | 2 INCH |
| Directory | CIS |
| Families | 583 |
| Family Description | Semicond,Rectifier,Hi-Voltage Fuses |
| Image Location | * Image |
| Industry | ELX |
| Interrupting Rating | 100 KILOAMPERE |
| InvoiceDescription | SC FUSE 700V 250A Q BLADE;700V SEMICOND FUSE |
| Item Number | 14099 |
| Length | 5.09 INCH |
| Long Description | SEMICONDUCTOR PROTECTION FUSE, ROUND, SEMICONDUCTOR TYPE; 5.09 INCH; UL 198L APPROVAL; 700 VAC/650 VDC VOLTAGE RATING; 2 INCH DIAMETER; 100 KILOAMPERE INTERRUPTING RATING; 250 AMPERE CURRENT RATING; BLADE TERMINAL TYPE |
| MSDS Form Number | * |
| Model | A70Q |
| Mounting | Bolt |
| Noun | * |
| Product Description | 700V SEMICOND FUSE |
| Product Keywords | WEBREADY |
| Product Name | Semiconductor fuse |
| ProductLine | MFP |
| Special Features | Lowest I2t of any fuse in this voltage rating for best overall protection 700V AC, 650V DC rating allows protection of greater variety of circuits Solid fill technology for extra reliability in performance |
| Standard | UL Recognized Component AC: Guide No. JFHR2 DC: Tested to UL Standard 198L Parameters RoHS Compliant |
| Terminal Type | BLADE |
| Type | North American Round Style;ROUND, SEMICONDUCTOR |
| UNSPSC | 39121628 |
| UPC | 78200114099 |
| Vendor Name | MERSEN (FORMERLY FERRAZ SHAWMUT INC) |
| Vendor Number | 782001 |
| Vendor Short Name | MFZ |
| Voltage Rating | 700 VAC;700 VAC/650 VDC |
