| Manufacturer Name | MERSEN USA Newburyport-MA, LLC |
| MfgPartNo | ATQ3-2/10 |
| AC Voltage Rating | 500 V |
| Additional Information | Body Material Glass-Melamine Laminate; Contact Material Tin Plated Copper; Mounting Type Clip; Application Supplemental Protection of Lighting, Solenoid, Motor and Transformer Circuit |
| Amperage Rating | 3.2 A |
| Application | Supplemental protection of lighting, solenoid, motor and transformer circuits |
| Approval | UL 248-14, CSA C22.2 |
| Base Price | 0.0000 |
| Body Material | GMG |
| Brand Name | Amp-Trap[R] |
| Catalog Number | ATQ3-2/10 |
| Characteristics | 12 Sec Time Delay (at 200 Percent Rated Load) |
| Class | Midget |
| Commerce Sector | Construction Materials |
| Commodity Code | 61200 |
| Commodity Description | Small Dimension Fuses |
| Connection | Ferrule |
| Connection Material | Tin-Plated Copper |
| CountryOfOrigin | MX |
| Current Rating | 3-2/10 Ampere |
| DDCATEGORY | 281 |
| Diameter | 0.41 Inch |
| Directory | CIS |
| Families | 281 |
| Family Description | Small Dimension Fuses |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 10 kA |
| Interrupting Rating | 10 Kiloampere |
| InvoiceDescription | Fuse ATQ - Midget - Time-Delay 500VAC 3.2A Ferrule;500V TD MIDGET FUSE |
| Item Number | 90607 |
| Length | 1.5 Inch |
| Long Description | MIDGET FUSE, 1.5 INCH; UL 248-14, CSA C22.2 APPROVAL; 500 VAC VOLTAGE RATING; 0.41 INCH DIAMETER; 10 KILOAMPERE INTERRUPTING RATING; 3-2/10 AMPERE CURRENT RATING; FERRULE TERMINAL TYPE; 12 SEC TIME DELAY (AT 200 PERCENT RATED LOAD) CHARACTERISTICS |
| MSDS Form Number | * |
| Model | ATQ |
| Mounting | Clip |
| Noun | * |
| Product Description | 500V TD MIDGET FUSE |
| Product Keywords | WEBREADY |
| Product Name | Midget fuses |
| ProductLine | MFP |
| Size | 1.5 x 0.41 in |
| Special Features | "Numerous ratings for a wide variety of applications up to 500VAC Time-delay (12 seconds at 200 percent rating) for circuits with high inrush current Can be used with UltraSafe Fuse holders 1 1/2"" x 13/32"" (10 mm x 38 mm) dimensions" |
| Standard | UL listed to standard 248-14 File E33925 CSA Certified to Standard C22.2 No. 248.14 |
| Terminal Type | Ferrule |
| Type | Midget Fuses |
| UNSPSC | 39121609 |
| UPC | 78200190607 |
| Vendor Name | MERSEN (FORMERLY FERRAZ SHAWMUT INC) |
| Vendor Number | 782001 |
| Vendor Short Name | MFZ |
| Voltage Rating | 500 VAC |
