| Manufacturer Name | MERSEN USA Newburyport-MA, LLC |
| MfgPartNo | GGM15 |
| Additional Information | RoHS Compliant; Mounting Type Clip; Application Electronic Circuit |
| Amperage Rating | 15 A |
| Application | Electronic circuits |
| Approval | UL, CSA |
| Base Price | 0.0000 |
| Brand Name | Ferraz Shawmut |
| Catalog Number | GGM15 |
| Characteristics | Fast Acting |
| Commerce Sector | Construction Materials |
| Commodity Code | 61200 |
| Commodity Description | Small Dimension Fuses |
| Connection | Ferrule |
| CountryOfOrigin | JP |
| Current Rating | 15 Amp |
| DDCATEGORY | 281 |
| Diameter | 0.2 Inch |
| Directory | CIS |
| Families | 281 |
| Family Description | Small Dimension Fuses |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 0.1 kA |
| Interrupting Rating | 100 Amp at 250 Volt AC |
| InvoiceDescription | 5X20MM FUSE 250V 15A GGM;SMALL DIM FUS |
| Item Number | 76820 |
| Length | 0.79 Inch |
| Long Description | ELECTRONIC FUSE, MINIATURE GLASS TUBE TYPE; 0.79 INCH; UL, CSA APPROVAL; 250 VOLT AC VOLTAGE RATING; 0.2 INCH DIAMETER; 100 AMP AT 250 VOLT AC INTERRUPTING RATING; 15 AMP CURRENT RATING; FERRULE TERMINAL TYPE; FAST ACTING CHARACTERISTICS; ROHS COMPLIANT |
| MSDS Form Number | * |
| Model | GGM |
| Mounting | Clip |
| Noun | * |
| Product Description | SMALL DIM FUS |
| Product Keywords | WEBREADY |
| Product Name | Midget fuses |
| ProductLine | MFP |
| Special Features | Glass Body, Fast Acting |
| Standard | UL/CSA Std. 248-14 1/16A - 3A, 250VAC, UL Listed, CSA certified, 4A - 8A, 125VAC, UL Listed, CSA certified, 10A & 15A, 250VAC, UL Recognized RoHS Compliant |
| Terminal Type | Ferrule |
| Type | 5 X 20 mm miniature fuses;Miniature Glass Tube |
| UNSPSC | 39121609 |
| UPC | 78200176820 |
| Vendor Name | MERSEN (FORMERLY FERRAZ SHAWMUT INC) |
| Vendor Number | 782001 |
| Vendor Short Name | MFZ |
| Voltage Rating | 250 VAC;250 Volt AC |
