| Manufacturer Name | MERSEN USA Newburyport-MA, LLC |
| MfgPartNo | STP480Y07M |
| Application | Industrial Control Panels Water treatment Smart grid & LV Metering Traffic / ITS applications. Intended for use on a wide range of low voltage applications inside appropriate enclosures |
| Base Price | 0.0000 |
| Connection | Box |
| CountryOfOrigin | MX |
| DDCATEGORY | 1170 |
| Families | 1170 |
| Family Description | Surge Suprsr-Prot Dev-Line Conditnr |
| Frequency Rating | 50/60 Hz |
| InvoiceDescription | SPD - Plugable STP 75 Series 480V L-N VPR 1500V L-N MCOV 320V 75 kA 3-pole MICRO;480V SPDEV |
| Material | PET (Polyethelene Terphthalate) |
| Mounting | DIN Rail |
| Operating Temperature Maximum | 185 F |
| Operating Temperature Minimum | -40 F |
| Phase | 3- |
| Product Description | 480V SPDEV |
| Product Keywords | WEBREADY |
| Product Name | Surge suppressers |
| ProductLine | MFP |
| Response Time | <25 |
| Size | 4.19 x 2.07 x 2.81;106.426 x 52.578 x 71.374 in;mm |
| Special Features | Designed with industry leading Mersen TPMOV technology Easy installation or retrofit Reversible chassis allows cable entry from top or bottom Replaceable modules with mechanical coding to avoid replacement errors 5-year warranty |
| Standard | ANSI/UL 1449 5th Edition, Open Type 1 SPD Listed, File E210793 ANSI/IEEE C62.41.1, C62.41.2, C62.45 CSA C22.2 No. 269 Certified, File 162842 RoHS Compliant |
| Type | DIN-RAIL UL CSA TYPE 1 |
| Type Of Indicators | Microswitch |
| UL SPD Type | Type 1 Component Assembly |
| UNSPSC | 39121610 |
| UPC | 78200147782 |
