| Manufacturer Name | MERSEN USA Newburyport-MA, LLC |
| MfgPartNo | TR70RID |
| AC Voltage Rating | 250 V |
| Additional Information | Body Material Polyester; Contact Material Copper/Tin-plated Copper; Mounting Type Clip; Includes Blow Fuse Indicator; Application Motor Circuit, Mains, Feeder, Branch Circuit, Transformer, Service Entrance Equipment, General-Purpose Equipment |
| Amperage Rating | 70 A |
| Application | Motor circuits Mains Feeders Branch circuits Transformers Service entrance equipment General-purpose equipment |
| Approval | UL 248-12, CSA C22.2 |
| Base Price | 0.0000 |
| Body Material | PolyTube |
| Brand Name | Tri-Onic[R] |
| Catalog Number | TR70RID |
| Characteristics | Time Delay |
| Class | Class RK5 |
| Commerce Sector | Construction Materials |
| Commodity Code | 61120 |
| Commodity Description | Dual Element Fuses |
| Connection | Blade |
| Connection Material | Tin-Plated Copper |
| CountryOfOrigin | MX |
| Current Rating | 70 Ampere |
| DDCATEGORY | 581 |
| Diameter | 1-1/16 Inch |
| Directory | CIS |
| Families | 581 |
| Family Description | Dual Element Fuses |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 200 kA |
| Interrupting Rating | 200 Kiloampere (AC), 20 Kiloampere (DC) |
| InvoiceDescription | Fuse TR-R - Class RK5 - Time-Delay 250VAC 250VDC 70A Blade SmartSpot;70A 250V TD FUSE |
| Item Number | 41531 |
| Length | 5-7/8 Inch |
| Long Description | LOW VOLTAGE UL POWER FUSE, CLASS RK5 TYPE; 5-7/8 INCH; UL 248-12, CSA C22.2 APPROVAL; 250 VAC/VDC VOLTAGE RATING; 1-1/16 INCH DIAMETER; 200 KILOAMPERE (AC), 20 KILOAMPERE (DC) INTERRUPTING RATING; 70 AMPERE CURRENT RATING; BLADE TERMINAL TYPE |
| MSDS Form Number | * |
| Model | TR-R |
| Mounting | Clip |
| Noun | * |
| Product Description | 70A 250V TD FUSE |
| Product Keywords | WEBREADY |
| Product Name | Cartridge fuses |
| ProductLine | MFP |
| Size | 5.88 x 1.06 in |
| Special Features | Time-delay Current-limiting AC & DC rated Optional solid state SmartSpot blown fuse indicator Time-delay for motor start-ups and transformer inrush currents without nuisance opening Current-limiting for low peak let-thru current Rejection-style design prevents replacement errors (when used with recommended fuse blocks) Easy-to-read label for quick brand recognition and replacement Metal-embossed date and catalog number for traceability and lasting identification Fiberglass body provides dimensional stability in harsh industrial settings High-grade silica filler ensures fast arc quenching and high current limitation |
| Standard | UL listed to standard 248-12 File E2137 CSA certified to standard C22.2 no. 248.12 DC listed to UL standard 248 TRS only |
| Terminal Type | Blade |
| Type | Class RK5 |
| Type Of Indicators | SmartSpot |
| UNSPSC | 39121606 |
| UPC | 78200141531 |
| Vendor Name | MERSEN (FORMERLY FERRAZ SHAWMUT INC) |
| Vendor Number | 782001 |
| Vendor Short Name | MFZ |
| Voltage Rating | 250 VAC;250 VAC/VDC |
