MERSEN USA Newburyport-MA, LLC
600V SPCL PURP FUSE

Mouse over image to zoom, click to enlarge

Description:
250V MIDGET TD FUSE

UPC:  78200190452

Part Number: ATMR9

UNSPSC: 39121609

Status:  UNKNOWN

Call for price



Specifications

Manufacturer Name MERSEN USA Newburyport-MA, LLC
MfgPartNo TRM8/10
AC Voltage Rating 250 V
Additional Information Body Style Cylindrical, Non-Rejection; Body Material Poly Tube, Glass-Melamine Laminate; Contact Material Tin Plated Copper; Mounting Type Clip; Application Small Motor, Small Transformer, Lighting Circuit, Control Circuit
Amperage Rating 0.8 A
Application Small motors Small transformers Lighting circuits Control circuits
Approval UL 248-14, CSA C22.2
Base Price 0.0000
Body Material GMG
Brand Name Tri-Onic[R]
Catalog Number TRM8/10
Characteristics 12 Second Time Delay (at 200 Percent Rated Load)
Class Midget
Commerce Sector Construction Materials
Commodity Code 61200
Commodity Description Small Dimension Fuses
Connection Ferrule
Connection Material Tin-Plated Copper
CountryOfOrigin MX
Current Rating 8/10 Amp
DDCATEGORY 281
Diameter 0.41 Inch
Directory CIS
Families 281
Family Description Small Dimension Fuses
Image Location * Image
Industry ELX
Interrupt Rating 10 kA
Interrupting Rating 10 Kiloamp
InvoiceDescription Fuse TRM - Midget - Time-Delay 250VAC 0.8A Ferrule;250V MIDGET TD FUSE
Item Number 74315
Length 1.5 Inch
Long Description MIDGET FUSE, 1.5 INCH; UL 248-14, CSA C22.2 APPROVAL; 250 VOLT AC VOLTAGE RATING; 0.41 INCH DIAMETER; 10 KILOAMP INTERRUPTING RATING; 8/10 AMP CURRENT RATING; FERRULE TERMINAL TYPE; 12 SECOND TIME DELAY (AT 200 PERCENT RATED LOAD) CHARACTERISTICS
MSDS Form Number *
Model TRM
Mounting Clip
Noun *
Product Description 250V MIDGET TD FUSE
Product Keywords WEBREADY
Product Name Midget fuses
ProductLine MFP
Size 1.5 x 0.41 in
Special Features "Numerous ratings for a wide variety of applications 250VAC rating in all sizes up to 30A Time-delay for circuits with high inrush currrent Can be used with UltraSafeTM fuse holders 1 1/2"" x 13/32"" (10mm x 38mm) dimensions"
Standard UL listed to standard 248-14 File E33925 CSA Certified to Standard C22.2 No. 248.14
Terminal Type Ferrule
Type Midget Fuses
UNSPSC 39121609
UPC 78200174315
Vendor Name MERSEN (FORMERLY FERRAZ SHAWMUT INC)
Vendor Number 782001
Vendor Short Name MFZ
Voltage Rating 250 VAC;250 Volt AC

Resources

CatalogNumber TRM8/10
Full Image
Manufacturer Specification Sheet

Package Information

SellPkgQty 1
