| Manufacturer Name | OZ-GEDNEY CO / NEER |
| MfgPartNo | ACV-75 |
| Additional Information | Includes Locknut; Used On Armored Cable/Flexible Metal Conduit; Applicable Standard NEMA FB-1 |
| Application | For Armored Cable, Flexible Metal Conduit, Non-Metallic And Service Entrance Cable |
| Approval | UL 514B, CSA C22.2 |
| Base Price | 0.0000 |
| Cable Conduit Type | Armored Cable/Flexible Metal Conduit |
| Cable Opening | Single |
| Catalog Number | ACV-75 |
| Commerce Sector | Construction Materials |
| Commodity Code | 24200 |
| Commodity Description | Bx, Mc, Armored Cable Fittings |
| Conductor Range | 29/32 - 1-1/64 IN |
| Connection | Male NPS Hub X Screw Clamp |
| Cord Size | 29/32 to 1-1/64 Inch |
| CountryOfOrigin | MX |
| DDCATEGORY | 1136 |
| Directory | CIS |
| Families | 1136 |
| Family Description | Bx, Mc, Armored Cable Fittings |
| Finish | Zinc Electroplated |
| Image Location | * Image |
| Industry | ELX |
| Installation | (2) Screw, Clamp |
| InvoiceDescription | 3/4 IN 90 DEG CONN AC/FMC;3/4 90D 2-SCR FLEX CONN |
| Item Number | 02055 |
| Long Description | FLEXIBLE CONDUIT CONNECTOR, 90 DEG TYPE; ELECTRO ZINC PLATED MALLEABLE IRON MATERIAL; (2) SCREW, CLAMP INSTALLATION; UL 514B, CSA C22.2 APPROVAL; 3/4 INCH TRADE SIZE; 29/32 TO 1-1/64 INCH CORD SIZE; NON-INSULATED THROAT TYPE |
| MSDS Form Number | * |
| Material | Malleable Iron;Electro Zinc Plated Malleable Iron |
| Model | ACV |
| Noun | * |
| Product Description | 3/4 90D 2-SCR FLEX CONN |
| Product Keywords | WEBREADY |
| Product Name | Flex connectors |
| ProductLine | OZ-G |
| Size | 3/4 IN |
| Special Features | To ground and secure armored cable and flexible metal conduit to boxes and enclosures; Furnished with locknuts |
| Standard | Third Party Certification: UL File Number E-11852 (Armored Cable And Flexible Metal Conduit), Hazardous Location: NEC 501-4(b) Class I Division II, NEC 350-5 (Grounding Means), CSA 9795 And 11584 (Armored cable and Flexible Metal Conduit), Applicable Third Party Standards: UL 514B, CSA C22.2 No.18, Federal Specification W-F-406E, NEMA : FB-1 |
| Throat Type | Non-Insulated |
| Trade Size | 3/4 Inch |
| Type | Type ACV 90 DEG Center Stopped 2-Screw Clamp Connector;90 Deg |
| UNSPSC | 39121419 |
| UPC | 78312602055 |
| Vendor Name | OZ-GEDNEY CO / NEER |
| Vendor Number | 783126 |
| Vendor Short Name | OZ-G |
