| Manufacturer Name | P&S WIRING DEVICES (PASS & SEYMOUR) |
| MfgPartNo | L820-R |
| Additional Information | Overall Dimension 1.61 Inch W x 1.19 Inch D x 3.28 Inch H; Applicable Standard NEMA WD-1/WD-6; Operating Temperature -40 to 75 Deg C |
| Amperage | 20.0 A |
| Amperage Rating | 20 |
| Application | Industrial |
| Application Sector | Industrial |
| Approval | UL 498, CSA |
| Base Price | 0.0000 |
| Brand Name | TURNLOK[R] |
| Catalog Number | L820-R |
| Commerce Sector | Construction Materials |
| Commodity Code | 51200 |
| Commodity Description | Receptacles & Surge Protectors |
| Configuration | L8-20R |
| Connection | Back and side wire |
| Connection Location | Back and Side |
| Constructional Feature | Impact Resistant |
| Country Code For ECCN | MX |
| CountryOfOrigin | MX |
| Current Rating | 20 Ampere |
| DDCATEGORY | 573 |
| Directory | CIS |
| Environmental Conditions | Flammability: UL94 V2: Operating Temperature: Maximum continuous +75C, minimum -40C without impact |
| Face Outer Diameter | 1.545 Inch |
| Families | 573 |
| Family Color | Black |
| Family Description | Receptacles & Surge Protectors |
| Features | Brass Mounting Strap |
| Ground Type | Grounding |
| Height | 3.28 in |
| Image Location | * Image |
| Indoor Outdoor | Indoor |
| Industry | ELX |
| InvoiceDescription | TURNLOK REC;LKG SGL RCPT-NEMA L8-20R |
| Item Number | 28205 |
| Long Description | LOCKING DEVICE RECEPTACLE, SINGLE LOCKING TYPE; NYLON MATERIAL; L8-20R CONFIGURATION; 3 WIRE(S); UL 498, CSA APPROVAL; 480 VAC VOLTAGE RATING; STRAP MOUNTING; 20 AMPERE CURRENT RATING; GROUNDING; 2 POLE(S); IMPACT RESISTANT; BACK WIRING |
| MSDS Form Number | * |
| Material | Nylon |
| Mounting | Wall;Strap |
| NEMA Configuration Code | L8-20R |
| NEMA Rating | L8-20R |
| Noun | * |
| Number Of Poles | 2 |
| Number Of Receptacles | 1.0 |
| Number Of Wires | 3 |
| Outlet Type | Locking |
| Product Depth | 1.19 in |
| Product Description | LKG SGL RCPT-NEMA L8-20R |
| Product Height | 2.29 in |
| Product Keywords | WEBREADY |
| Product Name | Electrical receptacles |
| Product Width | 1.61 in |
| ProductLine | P&S |
| Special Features | Compact, impact-resistant nylon face and body are ultrasonically welded together for unrivaled strength. Face color coding by voltage facilitates locating and mating of proper devices. One piece, high-grade brass contacts offer excellent conductivity and heat-rise resistance. Clearly marked NEMA configuration, rating, and third-party listing on each unit's face. Single-piece, solid brass mounting strap is free of easily loosened rivets found on other brands. Side and external screw-pressure-plate back wire capability. Accepts #14 - #10 AWG. |
| Standard | CULUS, UL498, CSA C22.2 No. 42 |
| Type | Turnlok Single Receptacle;Single Locking |
| UNSPSC | 39121406 |
| UPC | 78500728205 |
| Vendor Name | PASS & SEYMOUR INC WIRING DEVICES & ACCESSORIES |
| Vendor Number | 785007 |
| Vendor Short Name | P&S |
| Voltage | 480.0 V |
| Voltage Rating | 480;480 VAC |
| Wall Plate Included | No |
| Warranty Type | 1-Year Limited Warranty |
| Wattage | Electrical power is expressed in Amps and Volts. |
| Width | 1.19 in |
| Wire Connection Type | Screw Terminals |
| Wire Size | 14 - 10 |
| Wiring | Back |
