PAND CC688IW

Mini-Com Cat 6 UTP RJ45 Coupler Module, IW

Page Loading...
WOODHEAD/MOLEX (DANIEL WOODHEAD)
5P FEMALE TERMINATOR

Mouse over image to zoom, click to enlarge

Description:
Mini-Com Cat 6 UTP RJ45 Coupler Module, IW

UPC:  78172553529

Part Number: DN150

UNSPSC: 39121413

Status:  UNKNOWN

Retail Price:  $21.92 / EA
Your Price:  $21.72 / EA


Quantity  EA

Specifications

Manufacturer Name PANDUIT CORPORATION
MfgPartNo CC688IW
Additional Information RoHS Compliant; Overall Dimension 0.62 Inch Width x 1.09 Inch Depth x 0.71 Inch Height; Temperature Rating -10 to 149 Deg F; Application Ethernet, Token Ring, Voice Over Internet Protocol; Applicable Standard ANSI/TIA-568.2-D/1096-A, ISO 11801, IEC 60603-
Application Unshielded
Approval UL 1863
Base Price 0.0000
Brand Name Mini-Com[R], Pan-Net[R], TX6[TM]
Cable Entry T568A/T568B
Catalog Number CC688IW
Category 6
Color Off White;Off-White
Commerce Sector Construction Materials
Commodity Code 57180
Commodity Description Coupler,Splitter,Switch,Attenuator
Configuration 8-Position 8-Wire RJ45
Connection Type Snap-In, Snap-Out
CountryOfOrigin MEX
DDCATEGORY 1149
Depth 1.09 In.
Directory CIS
Families 1149
Family Description Coupler,Splitter,Switch,Attenuator
Image Location * Image
Industry ELX
InvoiceDescription Mini-Com Cat 6 UTP RJ45 Coupler Module, IW;CAT6 COUPLER MODULE
Item Number 01782
Long Description MODULE, UTP COUPLER JACK TYPE; ABS PLASTIC (BODY), COPPER (CONTACT) MATERIAL; OFF-WHITE COLOR; SNAP-IN, SNAP-OUT CONNECTION TYPE; 8-POSITION 8-WIRE RJ45 CONFIGURATION; UL 1863 APPROVAL; FACEPLATE, MODULAR PATCH PANEL MOUNTING; 6 CATEGORY
MSDS Form Number *
Material ABS;ABS Plastic (Body), Copper (Contact)
Model Mini-Com
Mounting Faceplate, Modular Patch Panel
Noun *
Product Description Mini-Com Cat 6 UTP RJ45 Coupler Module, IW
Product Keywords WEBREADY
Product Name Datacom cross connect system and accessories
ProductLine PAND
Slot Capacity 1
Standard Exceeds Channel Requirements of ANSI/TIA-568.2-D and ISO 11801 Standards for the Respective Category with up to 2 couplers per channel, Meets IEC 60603-7, Supports 2500 Connection Cycles with IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 an
Type Jack Module;UTP Coupler Jack
UNSPSC 43223301
UPC 07498301782
Vendor Name PANDUIT CORPORATION
Vendor Number 074983
Vendor Short Name PAND
Width 0.62 In.
Wiring Code T568A/B

Resources

CatalogNumber CC688IW
Full Image
Manufacturer Specification Sheet

Package Information

SellPkgQty 1
