PAND H100X034H1C

P1 Heat Shrink Label

Page Loading...
PANDUIT CORPORATION
P1 Heat Shrink Label

Mouse over image to zoom, click to enlarge

Description:
P1 Heat Shrink Label

UPC:  07498301014

Part Number: H100X034H1C

UNSPSC: 55121612

Status:  UNKNOWN

Retail Price:  $102.14 / EA
Your Price:  $77.47 / EA


Quantity  EA

Specifications

Manufacturer Name PANDUIT CORPORATION
MfgPartNo H100X034H1C
Additional Information RoHS Compliant; Shrink Ratio 3:1; Diameter 3/16 Inch; Temperature Rating -67 to 275 Deg F; Approval UL 224
Base Price 0.0000
Brand Name Panduit;P1[TM]
Catalog Number H100X034H1C
Color White
Commerce Sector Construction Materials
Commodity Code 64310
Commodity Description Markers & Marking Tapes
CountryOfOrigin CRI
DDCATEGORY 599
Directory CIS
Families 599
Family Description Markers & Marking Tapes
Image Location * Image
Industry ELX
InvoiceDescription P1 Heat Shrink Label;3/16DIA HTSHRK LBL
Item Number 01014
Length 1 in;1 Inch
Long Description LABEL, HEAT SHRINK, NON-ADHESIVE, FLATTENED TYPE; POLYOLEFIN MATERIAL; WHITE COLOR; 1 INCH; 0.06 INCH MIN. WIRE DIAMETER; 0.19 INCH MAX. WIRE DIAMETER; 18 TO 12 AWG WIRE SIZE; 100 PER CASSETTE QUANTITY
MSDS Form Number *
Material Polyolefin
Maximum Wire Diameter 0.19 Inch
Minimum Wire Diameter 0.06 Inch
Noun *
Printer Type PanTher LS8E/LS8EQ Thermal Transfer Printer
Product Description P1 Heat Shrink Label
Product Keywords WEBREADY
Product Name Printer labels
ProductLine PAND
Quantity 100 per Cassette
Size 1.00 x 0.34
Standard MIL-M-81531 and MIL-STD-202G Method 215K, Solution A, C, and D. UL Standard 224 for flammability.
Sub Brand P1
Temperature Range 275 F
Type Heat Shrink Label;Heat Shrink, Non-Adhesive, Flattened
UNSPSC 55121612
UPC 07498301014
Vendor Name PANDUIT CORPORATION
Vendor Number 074983
Vendor Short Name PAND
Width 0.34 In.
Wire Size 18 to 12 AWG
