PAND HSTT100-48-5C

Dry-Shrink HSTT100-48-5C Heat Shrink

Page Loading...
PANDUIT CORPORATION
Dry-Shrink HSTT100-48-5C Heat Shrink

Mouse over image to zoom, click to enlarge

Description:
Dry-Shrink HSTT100-48-5C Heat Shrink

UPC:  07498390666

Part Number: HSTT100-48-5C

UNSPSC: 39121723

Status:  UNKNOWN

Retail Price:  $13.09 / EA
Your Price:  $8.88 / EA


Quantity  EA

Specifications

Manufacturer Name PANDUIT CORPORATION
MfgPartNo HSTT100-48-5C
Additional Information Applicable Standard MIL-DTL-23053/5; ROHS Compliant
Application For Dry Locations
Approval UL
Base Price 0.0000
Brand Name Panduit;Dry-Shrink[TM]
Catalog Number HSTT100-48-5C
Color Colorless;Clear
Commerce Sector Construction Materials
Commodity Code 64340
Commodity Description Insulating Materials
Continuous Operating Temperature 275 F
CountryOfOrigin KOR
DDCATEGORY 1193
Directory CIS
Families 1193
Family Description Insulating Materials
Flammability N/A
Image Location * Image
Industry ELX
Inside Diameter 0.5 In.
InvoiceDescription Dry-Shrink HSTT100-48-5C Heat Shrink;HT SHRK TUBING
Item Number 90666
Length (5) 48 Inch
Long Description HEAT SHRINK TUBE, HEAT TYPE; CROSS LINKED POLYOLEFIN MATERIAL; CLEAR COLOR; (5) 48 INCH; 1 INCH MIN. EXPANDED DIAMETER; 0.5 INCH MAX. RECOVERED DIAMETER; UL APPROVAL; 600 V VOLTAGE RATING; 0.035 INCH THICKNESS; -67 TO 275 DEG F TEMPERATURE RATING
MSDS Form Number *
Material Cross Linked Polyolefin
Maximum Recovered Diameter 0.5 Inch
Minimum Expanded Diameter 1 Inch
Minimum Shrink Temperature 194 F
Model HSTT
Noun *
Outside Diameter 1 In.
Product Description Dry-Shrink HSTT100-48-5C Heat Shrink
Product Keywords WEBREADY
Product Name Heat shrinkable tube
ProductLine PAND
Shrink Ratio 2:1
Shrink Temperature 194 Deg F
Standard UL Recognized, CSA Approved, MIL SPEC
Sub Brand Dry-Shrink
Temperature Rating -67 to 275 Deg F
Thickness 0.035 In.;0.035 Inch
Type Heat Shrink;Heat
UNSPSC 39121723
UPC 07498390666
Vendor Name PANDUIT CORPORATION
Vendor Number 074983
Vendor Short Name PAND
Voltage Rating 600 V
Wall Type Thin

Resources

CatalogNumber HSTT100-48-5C
Full Image
Manufacturer Specification Sheet
MsdsUrl

Package Information

SellPkgQty 1
