PAND HSTT100-C2

Dry-Shrink HSTT100-C2 Heat Shrink

Page Loading...
PANDUIT CORPORATION
Dry-Shrink HSTT100-C2 Heat Shrink

Mouse over image to zoom, click to enlarge

Description:
Dry-Shrink HSTT100-C2 Heat Shrink

UPC:  07498391509

Part Number: HSTT100-C2

UNSPSC: 39121723

Status:  UNKNOWN

Retail Price:  $351.48 / EA
Your Price:  $233.92 / EA


Quantity  EA

Specifications

Manufacturer Name PANDUIT CORPORATION
MfgPartNo HSTT100-C2
Additional Information Applicable Standard MIL-DTL-23053/5; ROHS Compliant
Application For Dry Locations
Approval UL, CSA
Base Price 0.0000
Brand Name Dry-Shrink[TM]
Catalog Number HSTT100-C2
Color Red
Commerce Sector Construction Materials
Commodity Code 64340
Commodity Description Insulating Materials
CountryOfOrigin MUL
DDCATEGORY 1193
Directory CIS
Families 1193
Family Description Insulating Materials
Flammability Flame Retardant
Image Location * Image
Industry ELX
Inside Diameter After Heat Shrink 0.5 in
Inside Diameter Before Heat Shrink 0.5 in
InvoiceDescription Dry-Shrink HSTT100-C2 Heat Shrink;HEAT SHRK TUBING
Item Number 91509
Length 100 Ft Roll
Long Description HEAT SHRINK TUBE, HEAT TYPE; FLAME RETARDANT CROSS LINKED POLYOLEFIN MATERIAL; RED COLOR; 100 FT ROLL; 1 INCH MIN. EXPANDED DIAMETER; 0.5 INCH MAX. RECOVERED DIAMETER; UL, CSA APPROVAL; 600 V VOLTAGE RATING; 0.035 INCH THICKNESS
MSDS Form Number *
Material Flame Retardant Cross Linked Polyolefin
Maximum Recovered Diameter 0.5 Inch
Minimum Expanded Diameter 1 Inch
Minimum Shrink Temperature 194 F
Model HSTT
Noun *
Operating Temperature Maximum 275 F
Operating Temperature Minimum 275 F
Outside Diameter 1 in
Product Description Dry-Shrink HSTT100-C2 Heat Shrink
Product Keywords WEBREADY
Product Name Heat shrinkable tube
ProductLine PAND
Shrink Ratio 2:1
Shrink Temperature 194 Deg F
Standard UL Recognized, CSA Approved, MIL SPEC
Temperature Rating -67 to 275 Deg F
Thickness 0.035 in;0.035 Inch
Type Heat-Shrink;Heat
UNSPSC 39121723
UPC 07498391509
Vendor Name PANDUIT CORPORATION
Vendor Number 074983
Vendor Short Name PAND
Voltage Rating 600 V
Volume Resistivity Flame-Retardant
Wall Type Thin
