PAND HSTT200-48-5-2

Dry-Shrink HSTT200-48-5-2 Heat Shrink

Page Loading...
PANDUIT CORPORATION
Dry-Shrink HSTT200-48-5-2 Heat Shrink

Mouse over image to zoom, click to enlarge

Description:
Dry-Shrink HSTT200-48-5-2 Heat Shrink

UPC:  07498390611

Part Number: HSTT200-48-5-2

UNSPSC: 39121723

Status:  UNKNOWN

Your Price:  $27.03 / EA


Quantity  EA

Specifications

Manufacturer Name PANDUIT CORPORATION
MfgPartNo HSTT200-48-5-2
Additional Information APPLICABLE STANDARD MIL-DTL-23053/5
Application For Dry Locations
Approval UL, CSA
Base Price 0.0000
Brand Name PAN-SHRINK[T]
Catalog Number HSTT200-48-5-2
Color Red;RED
Commerce Sector Construction Materials
Commodity Code 64340
Commodity Description Insulating Materials
CountryOfOrigin CHN
DDCATEGORY 1193
Directory CIS
Families 1193
Family Description Insulating Materials
Flammability Flame Retardant
Image Location * Image
Industry ELX
Inside Diameter After Heat Shrink 1 in
Inside Diameter Before Heat Shrink 1 in
InvoiceDescription Dry-Shrink HSTT200-48-5-2 Heat Shrink;HT SHRK TUBING
Item Number 90611
Length (5) 48 INCH
Long Description HEAT SHRINK TUBE, HEAT TYPE; CROSS LINKED POLYOLEFIN MATERIAL; RED COLOR; (5) 48 INCH; 2 INCH MIN. EXPANDED DIAMETER; 1 INCH MAX. RECOVERED DIAMETER; UL, CSA APPROVAL; 600 V VOLTAGE RATING; 0.045 INCH THICKNESS; -67 TO 275 DEG F TEMPERATURE RATING
MSDS Form Number *
Material CROSS LINKED POLYOLEFIN
Maximum Recovered Diameter 1 INCH
Minimum Expanded Diameter 2 INCH
Minimum Shrink Temperature 194 F
Model HSTT
Noun *
Operating Temperature Maximum 275 F
Operating Temperature Minimum 275 F
Outside Diameter 2 in
Product Description Dry-Shrink HSTT200-48-5-2 Heat Shrink
Product Keywords WEBREADY
Product Name Heat shrinkable tube
ProductLine PAND
Shrink Ratio 2:1
Shrink Temperature 248 DEG F
Standard UL Recognized, CSA Approved, MIL SPEC
Temperature Rating -67 TO 275 DEG F
Thickness 0.045 in;0.045 INCH
Type Heat-Shrink;HEAT
UNSPSC 39121723
UPC 07498390611
Vendor Name PANDUIT CORPORATION
Vendor Number 074983
Vendor Short Name PAND
Voltage Rating 600 V
Volume Resistivity Flame-Retardant
Wall Type THIN

Resources

CatalogNumber HSTT200-48-5-2
Full Image
MsdsUrl

Package Information

SellPkgQty 1
