| Manufacturer Name | RACO INC |
| MfgPartNo | 2536 |
| Additional Information | Inside Opening Size 15/16 Inch; Approval UL |
| Application | and drop rods to support conduit from I-beams;bridle rings;For use with hangers;Hanger, Bridge Ring, Drop Rod to Support Conduit |
| Base Price | 0.0000 |
| Catalog Number | 2536 |
| Certified Listed | cULus Listed |
| Color | silver |
| Commerce Sector | Construction Materials |
| Commodity Code | 65400 |
| Commodity Description | Miscellaneous Fastening Hardware |
| Construction | Two piece, base and bolt |
| CountryOfOrigin | IN |
| DDCATEGORY | 604 |
| Description Long | 1.5 in Beam Clamp;15/16 in Inside Opening;Malleable Iron |
| Description Short | 1.5 in Beam Clamp;15/16 in Inside Opening;Malleable Iron |
| Directory | CIS |
| FEATURES Bullets | Rugged steel/malleable iron construction will last the lifetime of the installation;Zinc electroplated for corrosion resistance;Additional sizes available |
| FV Certified Listed | cULus Listed |
| Families | 604 |
| Family Description | Miscellaneous Fastening Hardware |
| Finish | Zinc plated;Zinc Electroplated |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | BEAM CLAMP 1-1/2 IN (5/16 IN-18) MAL IRN;1-1/2 MI BEAM CLAMP |
| Item Number | 02536 |
| Load | 525 lbs |
| Load Capacity | 60 Pound |
| Long Description | BEAM CLAMP, MALLEABLE IRON MATERIAL; ZINC ELECTROPLATED FINISH; 1-1/2 INCH MAX. JAW CAPACITY; HANGER, BRIDGE RING, DROP ROD TO SUPPORT CONDUIT APPLICATION; 60 POUND LOAD CAPACITY; 5/16 INCH-8 TPI SCREW SIZE; YES SUPPLIED WITH SCREW |
| MSDS Form Number | * |
| Material | Malleable Iron |
| Max Load Lbs | 60 lb. |
| Maximum Jaw Capacity | 1-1/2 Inch |
| Noun | * |
| Pallet Quantity | 8750 |
| Product Description | 1-1/2 MI BEAM CLAMP |
| Product Keywords | WEBREADY |
| Product Name | 1.5 in Beam Clamp;15/16 in Inside Opening;Malleable Iron |
| ProductLine | RACO |
| Screw Size | 5/16 Inch-8 TPI |
| Size | 1.36 in x 1.4 in x 1.72 in |
| Special Features | Zinc electro plated |
| Standard | cULus Listed |
| Supplied With Screw | Yes |
| Type | Conduit beam clamp |
| UNSPSC | 39121701 |
| UPC | 05016902536 |
| Vendor Name | RACO INC |
| Vendor Number | 050169 |
| Vendor Short Name | RACO |
