| Manufacturer Name | SIEMENS |
| MfgPartNo | 5SJ4104-7HG40 |
| Adapter Rating | N/A |
| Additional Information | Tripping Characteristic C; Device Depth 70 Millimeter; Temperature Rating -25 to 45 Deg C; Enclosure Rating IP20 |
| Application | BRANCH CIRCUIT PROTECTORS |
| Approval | UL 489, CSA C22.2 |
| Base Price | 0.0000 |
| Brand Name | Siemens |
| Catalog Number | 5SJ4104-7HG40 |
| Circuit Breaker Design | 5SJ4 |
| Class | C |
| Commerce Sector | Construction Materials |
| Commodity Code | 32331 |
| Commodity Description | 1 Pole Din Rail Mount Circuit Breakers |
| Connection | Identical wire screw connections on line and load side. |
| CountryOfOrigin | DE |
| Current At AC Rated Value | 4 |
| Current Rating | 4 Amp |
| DDCATEGORY | 1779 |
| Design Of The Product | Miniaturecircuit-breaker5SJ4 |
| Directory | CIS |
| Element | N/A |
| Families | 1779 |
| Family Description | 1 Pole Din Rail Mount Circuit Breakers |
| Frequency Rating | 50 Hz |
| Height | 90 |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 14kA |
| Interrupting Rating | 14 Kiloamp |
| InvoiceDescription | MCB 5SJ4 1P 240V 4A SAME PH 14K C-TRIP;1P 4A C-TRIP CB |
| Item Number | 93088 |
| Long Description | DIN RAIL MOUNT CIRCUIT BREAKER, THERMAL MAGNETIC TYPE; 18 MILLIMETER WIDTH X 76 MILLIMETER DEPTH X 90 MILLIMETER HEIGHT SIZE; 14 TO 4 AWG COPPER WIRE SIZE; UL 489, CSA C22.2 APPROVAL; 120/240 VOLT AC, 60 VOLT DC VOLTAGE RATING |
| MSDS Form Number | * |
| Material | N/A |
| Model | 5SJ4 |
| Mounting | On standard mounting rail (DIN 35mm) |
| Noun | * |
| Number Of Poles | 1 |
| Operating Voltage Minimum | 24 |
| Product Brand Name | SENTRON |
| Product Description | 1P 4A C-TRIP CB |
| Product Designation | Miniaturecircuitbreakers |
| Product Keywords | WEBREADY |
| Product Name | Circuit breakers |
| ProductLine | SIEM |
| Response Time | N/A |
| Short Circuit Rating | 14kA |
| Size | 18 Millimeter Width x 76 Millimeter Depth x 90 Millimeter Height |
| Special Features | 1-POLE |
| Standard | UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2 |
| Sub Brand | SENTRON |
| Supply Voltage At AC Rated Value | 400 |
| Supply Voltage With Single Phase Operation At AC Rated Value | 230V | |
| Terminal Type | Line/Load Screw |
| Tripping Characteristic Class | C |
| Tripping Residual Rated Value Derated Current At 40 Cel | 4 |
| Tripping Residual Rated Value Derated Current At 45 Cel | 3.900A |
| Tripping Residual Rated Value Derated Current At 50 Cel | 3.8 |
| Tripping Residual Rated Value Derated Current At 55 Cel | 3.700A |
| Tripping Residual Rated Value Derated Current At 60 Cel | 3.6 |
| Type | HSJ;Thermal Magnetic |
| Type Of Indicators | N/A |
| Type Of Voltage | AC/DC |
| UNSPSC | 39121601 |
| UPC | 75455493088 |
| Vendor Name | SIEMENS INDUSTRIAL CONTROLS |
| Vendor Number | 754554 |
| Vendor Short Name | SIEM3 |
| Voltage Rating | 240 V;120/240 Volt AC, 60 Volt DC |
| Width | 18 |
| Wire Size | 14 to 4 AWG Copper |
