| Manufacturer Name | SIEMENS ELECTRICAL DISTRIBUTION PRODUCTS |
| MfgPartNo | HF361SW |
| AC Voltage Rating | 240/480/600 V |
| Additional Information | Applicable Standard NEMA KS-1, CBC; Application Service Entrance Equipment; Includes Viewing Window |
| Ambient Temperature During Operating | 185.00000 F |
| Amperage Rating | 30 A |
| Application | DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS |
| Approval | UL 98 |
| Base Price | 0.0000 |
| Brand Name | SPEEDFAX |
| Catalog Number | HF361SW |
| Commerce Sector | Construction Materials |
| Commodity Code | 31310 |
| Commodity Description | Fusible Heavy Duty Safety Switches |
| Connection | MECHANICALLUGS |
| CountryOfOrigin | MX |
| Current Rating | 30 Ampere |
| DC Voltage Rating | 250 V |
| DDCATEGORY | 1706 |
| Directory | CIS |
| Enclosure | NEMA4X;NEMA 4X |
| Enclosure Material | 304 Stainless Steel |
| Families | 1706 |
| Family Description | Fusible Heavy Duty Safety Switches |
| Frequency Rating Maximum | TRUE |
| Frequency Rating Minimum | TRUE |
| Fuse Provision | Fusible |
| Fuse Type | Class H/J/R, Time Delay |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | HDSS FUS 3P3W 600V 30A N4X WIN;3P 30A 600V SFTY SW |
| Item Number | 22181 |
| Long Description | FUSIBLE SAFETY SWITCH, HEAVY DUTY SAFETY TYPE; 9.02 INCH W X 10.46 INCH D X 17.33 INCH H SIZE; 304 STAINLESS STEEL ENCLOSURE MATERIAL; 3 WIRE(S); UL 98 APPROVAL; NEMA 4X ENCLOSURE; 30 AMPERE CURRENT RATING |
| MSDS Form Number | * |
| Material | Stainless Steel |
| Model | HF |
| Mounting | SURFACE |
| Neutral Type | No |
| Noun | * |
| Number Of Poles | 3 |
| Number Of Wires | 3 |
| Operating Cycles | 10k |
| Operating Temperature Maximum | -20.20000 F |
| Operating Temperature Minimum | -20.20000 F |
| Power Rating | 3 HP at 240 VAC 1-Phase, 7-1/2 HP at 240 VAC, 15 HP at 480 VAC, 20 HP at 600 VAC 3-Phase, 5 HP at 250 VDC |
| Product Description | 3P 30A 600V SFTY SW |
| Product Keywords | WEBREADY |
| Product Name | Safety switch |
| ProductLine | SIEM5 |
| Size | 9.02 Inch W x 10.46 Inch D x 17.33 Inch H |
| Special Features | VIEWINGWINDOW |
| Standard | UL98 |
| Switch Type | SINGLETHROW |
| Type | HEAVYDUTYSWITCH;Heavy Duty Safety |
| UNSPSC | 39122205 |
| UPC | 78364322181 |
| Vendor Name | SIEMENS ELECTRICAL DISTRIBUTION PRODUCTS |
| Vendor Number | 783643 |
| Vendor Short Name | SIEM5 |
