SQD 9007ML02S0400

Limit Switch 240Vac 10Amp Ml +Options

Page Loading...
SQUARE-D/SCHNEIDER
Limit Switch 240Vac 10Amp Ml +Options

Mouse over image to zoom, click to enlarge

Description:
Limit Switch 240Vac 10Amp Ml +Options

UPC:  78590116943

Part Number: 9007ML02S0400

UNSPSC: 39122213

Status:  UNKNOWN

Call for price



Specifications

Manufacturer Name SQUARE-D/SCHNEIDER
MfgPartNo 9007ML02S0400
Actuator Head Type Metal Linear Parallel Roller Plunger
Additional Information Overall Dimension 1.58 Inch Width x 1.75 Inch Depth x 0.62 Inch Height; Number of Poles 1; Contact Material Silver
Approval UL, CSA, CE
Base Price 0.0000
Body Material Cast Zinc
Catalog Number 9007ML02S0400
Commerce Sector Construction Materials
Commodity Code 46150
Commodity Description Miniature & Snap Action Limit Switches
Connection Type 12 Foot 18 AWG Yellow SJTO Pre-Wired Cable
Contact Configuration SPDT, 1NO-1NC
Contact Rating 240 Volt AC 10 Amp, 28 Volt DC 5 Amp
CountryOfOrigin US
DDCATEGORY 2185
Differential Travel 0.03 Inch
Directory CIS
Enclosure NEMA 1/2/4/6/6P, IP67
Families 2185
Family Description Miniature & Snap Action Limit Switches
Image Location * Image
Industry ELX
InvoiceDescription Limit Switch 240Vac 10Amp Ml +Options;LIMIT SWITCH
Item Number 16943
Long Description HEAVY DUTY LIMIT SWITCH, MINIATURE TYPE; SPDT, 1NO-1NC CONTACT CONFIGURATION; 12 FOOT 18 AWG YELLOW SJTO PRE-WIRED CABLE CONNECTION TYPE; SNAP ACTION, SPRING RETURN OPERATION TYPE; 240 VOLT AC 10 AMP, 28 VOLT DC 5 AMP CONTACT RATING; UL, CSA, CE APPROVAL
MSDS Form Number *
Model 900ML
Noun *
Operating Force 80 Ounce (Tripping)
Operating Temperature -40 to 220 Deg F
Operating Travel 0.19 Inch
Operation Type Snap Action, Spring Return
Pretravel 0.08 Inch
Product Description Limit Switch 240Vac 10Amp Ml +Options
Product Keywords WEBREADY
Product Name Limit switch
ProductLine SQD
Type Miniature
UNSPSC 39122213
UPC 78590116943
Vendor Name SQUARE D/TELEMECANIQUE
Vendor Number 785901
Vendor Short Name SQD

Resources

CatalogNumber 9007ML02S0400
Full Image
Manufacturer Specification Sheet

Package Information

SellPkgQty 1
