| Manufacturer Name | SQUARE-D/SCHNEIDER |
| MfgPartNo | 9007T5 |
| Action | Lateral approach, 2 directions;CW and CCW;from left and right |
| Actuator | Spring return neutral position without operating lever zinc low differential |
| Application | 9007C |
| Approval | UL, CSA, CE |
| Associated Body | 9007C |
| Associated Lever | 9007C |
| Base Price | 0.0000 |
| Brand Name | 9007 |
| Catalog Number | 9007T5 |
| Commerce Sector | Construction Materials |
| Commodity Code | 46160 |
| Commodity Description | Limit Switch Arms, Actuators & Operators |
| Country Of Origin | Mexico NULL |
| CountryOfOrigin | MX |
| DDCATEGORY | 2186 |
| Differential Travel | 2 DEG |
| Directory | CIS |
| Environmental Conditions | STANDARD ENVIRONMENT |
| Families | 2186 |
| Family Description | Limit Switch Arms, Actuators & Operators |
| Function Available | Neutral position |
| Head Type | Rotary head |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | Limit switch head, 9007, c;LIMIT SWITCH HEAD C |
| Item Number | 81224 |
| Long Description | LIMIT SWITCH HEAD, 9007C SERIES LIMIT SWITCH USED ON; CLOCKWISE/COUNTERCLOCKWISE, NEUTRAL POSITION, SPRING RETURN OPERATION TYPE; UL, CSA, CE APPROVAL; -20 TO 185 DEG F OPERATING TEMPERATURE; 4 LB-INCH OPERATING FORCE; 2 DEG DIFFERENTIAL TRAVEL |
| MSDS Form Number | * |
| Model | 9007 |
| Movement Of Operating Head | Rotary |
| Net Weight | 1.25 lb |
| Noun | * |
| Operating Force | 4 LB-INCH |
| Operating Temperature | -20-185 AF;-20 TO 185 DEG F |
| Operation Type | CLOCKWISE/COUNTERCLOCKWISE, NEUTRAL POSITION, SPRING RETURN |
| Positive Opening | Without |
| Pretravel | 5 DEG |
| Product Description | Limit Switch Head C |
| Product Keywords | WEBREADY |
| Product Name | Limit switch |
| Product Weight | 1.25 lb |
| ProductLine | SQD |
| Series Name | Heavy duty |
| Special Features | NEUTRAL POSITION |
| Standard | UL LISTED FILE NUMBER E42259 CCN NKCR - CSA CERTIFIED FILE NUMBER LR25490 CLASS 3211-03 - CE MARKED |
| Sub Brand | 9007C |
| Total Travel | 90 DEG |
| Type | Limit switch head |
| Type Of Approach | Lateral approach, 2 directions NULL |
| Type Of Operator | Spring return neutral position without operating lever zinc low differential NULL |
| UNSPSC | 39122213 |
| UPC | 78590181224 |
| Used On | 9007C SERIES LIMIT SWITCH |
| Vendor Name | SQUARE D/TELEMECANIQUE |
| Vendor Number | 785901 |
| Vendor Short Name | SQD |
