SQD 9070T350D31

Industrial control transformer, Type T, 1 phase, 350VA, 240x480V primary, 120/240V secondary, 50/60Hz

Page Loading...
SQUARE-D/SCHNEIDER
Industrial control transformer, Type T, 1 phase, 350VA, 240x480V primary, 120/240V secondary, 50/60Hz

Mouse over image to zoom, click to enlarge

Description:
Industrial control transformer, Type T, 1 phase, 350VA, 240x480V primary, 120/240V secondary, 50/60Hz

UPC:  78590168916

Part Number: 9070T350D31

UNSPSC: 39121002

Status:  UNKNOWN

Your Price:  $661.00 / EA


Quantity  EA

Specifications

Manufacturer Name SQUARE-D/SCHNEIDER
MfgPartNo 9070T350D31
Additional Information RoHS/REACH Compliant; Type T; Number of Phase 1; Winding Material Copper
Applicable Standard EN 61558
Application FSC2
Approval UL, CUL, CSA, CE, NOM
Base Price 0.0000
Brand Name T
Catalog Number 9070T350D31
Commerce Sector Construction Materials
Commodity Code 39210
Commodity Description Core & Coil Industrial Control Transformers
Connection SCREW CLAMP
CountryOfOrigin US
DDCATEGORY 2081
Depth 5.11 in
Directory CIS
Electrical Connection Screw clamp terminals
Enclosure OPEN
Families 2081
Family Description Core & Coil Industrial Control Transformers
Fingersafe Cover Compatibility FSC2
Frequency Rating 50/60 Hertz
Height 3.84 in
Image Location * Image
Industry ELX
Insulation 130 DEGREES C
Insulation Class 130
InvoiceDescription Industrial control transformer, Type T, 1 phase, 350VA, 240x480V primary, 120/240V secondary, 50/60Hz;TRFMR CONTROL 500VA
Item Number 68916
KVA Rating 0.35
Long Description INDUSTRIAL CONTROL TRANSFORMER, 4.5 INCH WIDTH X 5.11 INCH DEPTH X 3.84 INCH HEIGHT SIZE; 50/60 HERTZ FREQUENCY RATING; UL, CUL, CSA, CE, NOM APPROVAL; EN 61558 APPLICABLE STANDARD; 0.38 INCH LENGTH X 0.2 INCH WIDTH SLOT MOUNTING
MSDS Form Number *
Material Copper winding
Model 9070
Mounting PANEL;0.38 Inch Length x 0.2 Inch Width Slot
Noun *
Number Of Phases 1 phase
Phase 1-PHASE
Power Rating 350 Volt Amp
Primary Voltage 240X480V OR 230X460V OR 220X440V;240/480 Volt AC, 230/460 Volt AC, 220/440 Volt AC
Product Description Industrial control transformer, Type T, 1 phase, 350VA, 240x480V primary, 120/240V secondary, 50/60Hz
Product Keywords WEBREADY
Product Name Power supply transformers
Product Type Industrial Control Transformer
ProductLine SQD
Rated Power In Va Metric 350.0;350 VA UL;350 VA CSA;350 VA NOM;250 VA V.A
Secondary Voltage 120/240V OR 115/230V OR 110/220V;120/240 Volt AC, 115/230 Volt AC, 110/220 Volt AC
Size 4.5 Inch Width x 5.11 Inch Depth x 3.84 Inch Height
Special Features INDUSTRIAL CONTROL TRANSFORMER,COPPER WINDING,SCREW CLAMP TERMINALS
Standard UL LISTED, CSA, CE MARKED
Temperature Rating 80 DEGREES C
Temperature Rise 80 C;80 Deg C
Terminal Type Screw Clamp
Type Industrial Control Transformer
UNSPSC 39121002
UPC 78590168916
Vendor Name SQUARE D/TELEMECANIQUE
Vendor Number 785901
Vendor Short Name SQD
Width 4.5 in
Winding COPPER

Resources

CatalogNumber 9070T350D31
Full Image
Manufacturer Specification Sheet
MfrProductUrl

Package Information

SellPkgQty 1
