SQD 9999SX8

NEMA Motor Starter and contactor, Type S, auxiliary contact, 1 NO/1 NC isolated contact, external, field convertible

Page Loading...
SQUARE-D/SCHNEIDER
NEMA Motor Starter and contactor, Type S, auxiliary contact, 1 NO/1 NC isolated contact, external, field convertible

Mouse over image to zoom, click to enlarge

Description:
NEMA Motor Starter and contactor, Type S, auxiliary contact, 1 NO/1 NC isolated contact, external, field convertible

UPC:  78590173353

Part Number: 9999SX8

UNSPSC: 39121529

Status:  UNKNOWN

Your Price:  $116.00 / EA


Quantity  EA

Specifications

Manufacturer Name SQUARE-D/SCHNEIDER
MfgPartNo 9999SX8
Application contactor; starter
Base Price 0.0000
Brand Name Type S
Catalog Number 9999SX8
Certifications UL Recognized
Coil Voltage <= 600 V AC 50/60 HZ
Commerce Sector Construction Materials
Commodity Code 41920
Commodity Description Starter Accessories
Connection SCREW CLAMP
Contact Configuration 1 NO + 1 NC;1NO-1NC
Contact Rating 10A;600 Volt AC 10 Amp
CountryOfOrigin MX
DDCATEGORY 2142
Depth 4.5 in
Directory CIS
Families 2142
Family Description Starter Accessories
Height 1.5 in
Image Location * Image
Industry ELX
InvoiceDescription NEMA Motor Starter and contactor, Type S, auxiliary contact, 1 NO/1 NC isolated contact, external, field convertible;CONTACTOR+STARTER
Item Number 73353
Long Description ISOLATED AUXILIARY CONTACT, AUXILIARY CONTACT TYPE; CLASS 8502/8536/8736 TYPE SA TO SJ CONTACTOR/STARTER USED ON; 1NO-1NC CONTACT CONFIGURATION; 600 VOLT AC 10 AMP CONTACT RATING; SCREW CLAMP TERMINAL TYPE; 00 TO 7 NEMA SIZE; LEFT/RIGHT MOUNTING LOCATION
MSDS Form Number *
Maximum Load Current 10 A
Model 9999
Mounting SCREW-IN
Mounting Location Left/Right
NEMA Size 3;4;00;1;6;2;5;7;0;00 to 7
Net Weight Metric 0.14 kg
Noun *
Product Description NEMA Motor Starter and contactor, Type S, auxiliary contact, 1 NO/1 NC isolated contact, external, field convertible
Product Keywords WEBREADY
Product Name Contactors
Product Weight 0.31 lb
ProductLine SQD
Rated Breaking Capacity 6 A 120 V AC inductive control circuit UL 508;3 A 240 V AC inductive control circuit UL 508;1.2 A 600 V AC inductive control circuit UL 508;1.5 A 480 V AC inductive control circuit UL 508;10 A <= 600 V AC resistive control circuit UL 508
Rated Operational Voltage <= 600 V AC 50/60 Hz
Size 4.5 in
Special Features SCREW CLAMP TERMINAL
Standard CSA-UL RECOGNIZED-UL LISTED
Sub Brand SCHNEIDER ELECTRIC
Terminal Type Screw Clamp
Type Auxiliary Contact Module;Auxiliary Contact
UNSPSC 39121529
UPC 78590173353
Uc Control Circuit Voltage <= 600 V AC 50/60 Hz NULL
Used On Class 8502/8536/8736 Type SA to SJ Contactor/Starter
Used With contactor; starter NULL
Vendor Name SQUARE D/TELEMECANIQUE
Vendor Number 785901
Vendor Short Name SQD
Width 3.0 in
