| Manufacturer Name | SQUARE-D/SCHNEIDER |
| MfgPartNo | QO2L30S |
| Amperage | 30 A |
| Amperage Rating | 30 A |
| Application | DESIGNED TO MEET RESIDENTIAL, COMMERCIAL AND INDUSTRIAL REQUIREMENTS TO PROTECT ELECTRICAL SYSTEMS, EQUIPMENT AND PEOPLE. |
| Approval | UL, NOM |
| Base Price | 0.0000 |
| Brand Name | QO;QO[TM] |
| Bus Material | Tin Plated Aluminum |
| Cable Size | AWG 14...AWG 10 copper;AWG 12...AWG10 aluminium |
| Catalog Number | QO2L30S |
| Circuit Configuration | 1 Phase 3 Wire |
| Commerce Sector | Construction Materials |
| Commodity Code | 33110 |
| Commodity Description | Single Phase Main Lug Load Centers |
| CountryOfOrigin | MX |
| Cover Finish | Baked enamel Gray NULL |
| Cover Type | Surface cover;Surface |
| Current Rating | 30 Ampere |
| DDCATEGORY | 1852 |
| Device Composition | Grounding bar (ordered separately) | |
| Directory | CIS |
| Electrical Connection | Lugs |
| Enclosure | Baked enamel Gray;Welded sheet steel;1 |
| Enclosure Size Designation | 1 |
| Enclosure Type | NEMA 1, Indoor |
| Families | 1852 |
| Family Description | Single Phase Main Lug Load Centers |
| Feed Location | Top |
| Ground Bar | Grounding bar (ordered separately) |
| Grounding Bar | Grounding bar (ordered separately) NULL |
| Height | 6.73 in |
| Height Metric | 171.0 mm |
| Image Location | * Image |
| Industry | ELX |
| Interrupt Rating | 10 kA |
| Interrupting Rating | 10 Kiloampere |
| InvoiceDescription | Load center, QO, 1 phase, 2 spaces, 2 circuits, 30A fixed main lugs, NEMA1, surface cover, UL;LOAD CENTER QO MLO 240V |
| Item Number | 78507 |
| Line Rated Current Metric | 30.0 A |
| Load Center Type | Fixed Mains (lugs) |
| Long Description | LOADCENTER, FIXED MAIN LUG TYPE; 3.81 INCH W X 3 INCH D X 6.72 INCH H SIZE; 2 MAX. NUMBER OF CIRCUITS; 2 MAX. NUMBER OF SPACES; UL, NOM APPROVAL; 120/240 VAC VOLTAGE RATING; 10 KILOAMPERE INTERRUPTING RATING; 30 AMPERE CURRENT RATING; SURFACE COVER TYPE |
| MSDS Form Number | * |
| Main Wire Size | 12 to 10 AWG (Aluminum), 14 to 10 AWG (Copper) |
| Maximum Number Of Circuits | 2 |
| Maximum Number Of Spaces | 2 |
| Maximum Number Of Tandem Breakers | 0 NULL |
| Neutral Type | Split Branch |
| Noun | * |
| Number Of Circuits | 2.0 |
| Number Of Feeders | 2 |
| Number Of Spaces | 2.0 |
| Number Of Tandem Circuit Breakers | 0.0 |
| Phase | 1 |
| Product Description | Load center, QO, 1 phase, 2 spaces, 2 circuits, 30A fixed main lugs, NEMA1, surface cover |
| Product Keywords | WEBREADY |
| Product Name | Load centers |
| ProductLine | SQD |
| Rated Current | 30 A |
| Rated Operational Voltage | 120/240 V AC |
| Short Circuit Current Metric | 10.0 kA |
| Size | 3.81 Inch W x 3 Inch D x 6.72 Inch H |
| Special Features | Tin plated aluminium busbar |
| Standard | UL LISTED |
| Sub Brand | QO |
| Surface Finish | Baked enamel Gray |
| Tightening Torque | Main lugs 35 lb.in, AWG 14...AWG 10, aluminium/copper;main lugs 35 lb.in, AWG 12...AWG10, aluminium/copper |
| Type | Load Center;Fixed Main Lug |
| UNSPSC | 39121101 |
| UPC | 78590178507 |
| Vendor Name | SQUARE D/TELEMECANIQUE |
| Vendor Number | 785901 |
| Vendor Short Name | SQD |
| Voltage Rating | 120/240 VAC |
| Width | 3.82 in |
| Width Metric | 97.0 mm |
| Wire Size | AWG 14...AWG 10 copper;AWG 12...AWG10 aluminium NULL |
| Wiring Configuration | 3-wire |
