| Manufacturer Name | WOODHEAD/MOLEX (DANIEL WOODHEAD) |
| MfgPartNo | 7R3006A19A120 |
| Additional Information | APPLICABLE STANDARD VDE 0110 |
| Amperage Rating | 4 A |
| Application | CONVEYOR, HYDRAULIC CYLINDER, MODULAR CONTROL, PNEUMATIC CYLINDER, ROBOT, TUBULAR PHOTOELECTRIC/TUBULAR PROXIMITY SENSOR |
| Approval | UL, CSA |
| Base Price | 0.0000 |
| Brand Name | MICRO-CHANGE[R] |
| Catalog Number | 7R3006A19A120 |
| Commerce Sector | Construction Materials |
| Commodity Code | 02400 |
| Commodity Description | Cords Sets |
| Conductor Range | 22 |
| Connection | External Thread |
| CountryOfOrigin | MX |
| Current Rating | 4 AMPERE |
| DDCATEGORY | 22 |
| Directory | CIS |
| Enclosure | NEMA 6P, IP68 |
| Environmental Conditions | IP67 |
| Families | 22 |
| Family Description | Cords Sets |
| Image Location | * Image |
| Industry | ELX |
| InvoiceDescription | MIC 3P MR 12IN. 1/2NPT #22 - PVC;MIC 3P MR 1/2NPT |
| Item Number | 53471 |
| Keyway Type | DUAL |
| Long Description | CORD SET, MALE TYPE; ANODIZED ALUMINUM SHELL, GOLD OVER PALLADIUM/NICKEL PLATED COPPER ALLOY CONTACT, NITRILE RUBBER O RING, NYLON INSERT, STEEL LOCKNUT MATERIAL; UL, CSA APPROVAL |
| MSDS Form Number | * |
| Material | ANODIZED ALUMINUM SHELL, GOLD OVER PALLADIUM/NICKEL PLATED COPPER ALLOY CONTACT, NITRILE RUBBER O RING, NYLON INSERT, STEEL LOCKNUT |
| Mounting | 1/2 INCH-14NPT |
| NEMA Rating | 6 |
| Noun | * |
| Number Of Poles | 3 |
| Orientation | Straight |
| Product Description | MIC 3P MR 1/2NPT |
| Product Keywords | WEBREADY |
| Product Name | Circular connectors |
| ProductLine | WOOD |
| Receptacle Type | STRAIGHT |
| Size | 0.305m |
| Temperature Rating Maximum | 176 F |
| Temperature Rating Minimum | -4 F |
| Terminal Type | 22 AWG 12 INCH PIGTAIL, PVC |
| Type | Single Ended (pigtail);MALE |
| UNSPSC | 39121413 |
| UPC | 78172553471 |
| Vendor Name | WOODHEAD/MOLEX/ELEC/INDUS/NET/PASV |
| Vendor Number | 781725 |
| Vendor Short Name | WMIE |
| Voltage Rating | 250V AC/DC;250 V |
| Wire Code | 1-GREEN 2-RED/BLACK 3-RED-WHITE |
